Video

Graphics

10.3.3 Additional Information

Display of 2D Measurements

Note
Note
Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 Revision 4
To see demo video, press [Start Demo Video] .
1. To measure the angle, select the [Manual] or [Auto] item in the menu area.
2. After the angle measurement, select [Show Graphics].
BPD: Type of Measurement GA: Gestational Age EDD: Estimated Date of Delivery
"GA=OOR" means that the "Gestational Age is Out Of Range" - no standard curve available
for current input.
EDD (Estimated Day of Delivery) is only displayed, if the selection of the field "Show EDD calc.
on screen" in the Measure Setup is "checked".
There are 3 possibilities to display 2D Measurement results:
1.
Measurements and Calculations
Figure 10-6 SonoL&D Video
Figure 10-7 SonoL&D Graphics
10-19
