Page 1 Title page Alcatel-Lucent 1665 Data Multiplexer Extend (DMXtend) | Release 10.0 Installation Manual 365-372-327R10.0 Issue 1 | January 2013...
Page 2 In rare instances, unauthorized individuals make connections to the telecommunications network through the use of remote access features. In such an event, applicable tariffs require that the customer pay all network charges for traffic. Alcatel-Lucent cannot be responsible for such charges and will not make any allowance or give any credit for charges that result from unauthorized access.
Page 3: Table Of Contents
Material content compliance ........................xix Safety Laser safety ............................... 1-1 Electrostatic discharge ESD considerations ....................1-3 Laser product classification ........................1-9 Alcatel-Lucent 1665 DMXtend optical specifications ................1-11 Part I: Physical and power installation Physical installation Planning ..............................2-1 Inspection ..............................2-5 Alcatel-Lucent 1665 DMXtend center divider ..................
Page 4 ® Use of WaveStar CIT software ........................ 5-6 Circuit pack program version verification ....................5-12 Alcatel-Lucent 1665 DMXtend shelf initialization ................5-13 Stand-alone installation testing LBO software settings ..........................6-4 Clearing alarms ............................6-7 Local equipment and cross-connect tests ....................6-8 DS1/E1 testing ............................
Page 5 Connecting the ring (Mains) to the WDMX ................... 8-14 Removing provisioning and equipage from the LNW785 ..............8-16 Part IV: Miscellaneous detailed installation procedure and reference material Fiber cleaning Equipment requirements and recommendations ..................A-2 .................................................... Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 6 Pin and connector background ........................D-2 Repair kits and tools ..........................D-3 Simple repair methods ..........................D-4 Replacement methods ..........................D-5 Fiber labeling Fiber description ............................E-1 Fiber labels ..............................E-3 Glossary Terms and definitions .................................................... Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 7 Alcatel-Lucent 1665 DMXtend documentation set ..............1-xviii Safety Laser classes ..........................1-10 Alcatel-Lucent 1665 DMXtend optical circuit pack laser safety specifications ......1-11 Alcatel-Lucent 1665 DMXtend optical PTM laser safety specifications ........1-12 Dispersion-limited receiver sensitivity for OC-192 DWDM PTMs .......... 1-21 Computer requirements .........................I-5...
Page 8 3-26 RJ-45 to DB-9 connector connections ..................3-65 Circuit pack installation Alcatel-Lucent 1665 DMXtend shelf power supply requirements ..........4-2 R10.0circuit pack slot compatibility .................... 4-6 OC-3 mains with 6 STS-1s of vt switch fabric ................4-8 OC-12 mains with 12 STS-1s of vt switch fabric ................ 4-8 OC-48 Mains with 48 STS-1s of vt switch fabric ................
Page 9 Circuit pack attenuation table .......................C-4 PTM attenuation table ........................C-5 LBOs based on attenuation ......................C-7 Backplane pin replacement Backplane locations of METRAL™ pins ................... D-3 Metral™ pins ..........................D-3 Fiber labeling .................................................... Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 10 List of tables ......................................................................................................Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 11 DS1 and DS3 hybrid cable routing ................... 3-31 3-10 10/100BASE-T/TX cable connections ..................3-37 3-11 10/100BASE-T cable routing ..................... 3-37 3-12 IAO LAN/TCP-IP cable connection to rear of Alcatel-Lucent 1665 DMXtend ...... 3-42 3-13 Modem cable connection ......................3-45 3-14 Sync cable connections ......................3-47 3-15 Office alarm cable connections ....................
Page 12 Miscellaneous discrete cable routing ..................3-55 3-19 Optical fiber routing ........................3-60 Circuit pack installation Power connections on Alcatel-Lucent 1665 DMXtend backplane ..........4-4 Stand-alone node setup Stand-alone installation testing Alcatel-Lucent 1665 DMXtend shelf backplane ............... 6-54 Miscellaneous (environmental) discrete functions ..............6-57...
Page 13: About This Document
VT1.5 added to integrated test access capability • Intended audience This installation manual is intended to provide individuals and customers the information and procedures necessary to install, self-test and turn up the Alcatel-Lucent 1665 DMXtend system..................................................... x i i i Alcatel-Lucent 1665 DMXtend R10.0...
Page 14: How To Use This Document
Part I: “Physical and power installation” Part I covers Chapters 2, 3, and 4. These sections covers the physical mounting of the Alcatel-Lucent 1665 DMXtend shelf using the Horizontal Bay Mount. This section includes the running and connecting of power cables, interconnecting cables, alarm cables, and as required, external timing, communication cables, and covers initial circuit pack installation (not seated).
Page 15 Chapter 6, “Stand-alone installation testing” This chapter is to verify proper transmission cabling installation and R10.0 functionality as well as the associated functionality of the Alcatel-Lucent 1665 DMXtend shelf. Part III: “Network turn-up and testing” Part III covers fiber connections between nodes in a ring. It is not intended to replace acceptance test procedures.
Page 16 .................................................... Chapter 8, “WDMX setup and testing: integration procedures” This chapter is used to verify WDMX connectivity between Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) nodes. The chapter includes the LNW785 8 channel Optical Multiplexer Demultiplexer (OMD) circuit pack. It is not intended to replace acceptance test procedures.
Page 17: Safety Information
Adhere to the following safety precautions: Electrostatic discharge (ESD) • You must be properly grounded when making contact with the Alcatel-Lucent 1665 DMXtend frame and handling circuit packs, disk drives, and tapes. Wrist strap ground cords should be routinely tested for the minimum 1-megohm resistance.
Page 18: Technical Support
109789180 Alcatel-Lucent 1665 Data Multiplexer Extend (DMXtend) Release 10.0.0 Eletronic Documentation Library Technical support For technical support, contact your local Alcatel-Lucent customer support team. See the Alcatel-Lucent Support web site (http://www.alcatel-lucent.com/support) for contact information..................................................... x v i i i Alcatel-Lucent 1665 DMXtend R10.0...
Page 19: How To Order
Directive applies to electrical and electronic products placed on the EU market after 1 July 2006, with various exemptions, including an exemption for lead solder in network infrastructure equipment. Alcatel-Lucent products shipped to the EU after 1 July 2006 comply with the EU RoHS Directive.
Page 20 Moreover, in compliance with legal requirements and contractual agreements, where applicable, Alcatel-Lucent will offer to provide for the collection and treatment of Alcatel- Lucent products bearing the logo at the end of their useful life, or products. For...
Page 21: Safety
Laser safety System design The Alcatel-Lucent system complies with FDA/CDRH 21 CFR 1040.10 and 1040.11 as a Class I and with IEC 60825-1 as a Class 1 Optical Fiber Telecommunication laser product. The system has been designed to ensure that the operating personnel is not endangered by laser radiation during normal system operation.
Page 22: Safety
LASER DE CLASSE 1M INVISIBLE LORSQUE L’APPAREIL EST OUVERT ET QUE LA FIBRE EST DÉCONNECT E. É Ne pas regarder directement au moyen d’un instrument optique. 848950572 .................................................... 1 - 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 23: Electrostatic Discharge Esd Considerations
Dry air allows greater static charges to accumulate. Higher potentials are measured in areas with low relative humidity, but potentials high enough to cause damage can occur anywhere..................................................... 1 - 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 24 When grounding jacks are not provided, an alligator clip adapter enables connection to bay frame ground..................................................... 1 - 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 25: Static Control Wrist Strap
Safety .................................................... Figure 1-1 Static control wrist strap GROUND CONNECTION .................................................... 1 - 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 26 Never spill liquids of any kind on the product..................................................... 1 - 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 27 Incorrect reassembly can cause electrical shock when the unit is subsequently used. 19. Some of the Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) hardware modules contain FDA/CDRH Class I/IEC Class 1 single-mode laser products that are enclosed lightwave transmission systems.
Page 28 If the product has been dropped or the cabinet has been damaged. f. If the product exhibits a distinct change in performance. SAVE THESE INSTRUCTIONS .................................................... 1 - 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 29: Laser Product Classification
1. The Accessible Emission Limits (AEL) are different. 2. Class 3A applies to all wavelengths. 3. Class 3B requires strict engineering controls. 4. Classification is under single fault conditions..................................................... 1 - 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 30: Laser Classes
The circuit packs themselves, however, may be IEC Class 1 or 3A or FDA/CDRH Class I or IIIb..................................................... 1 - 1 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 31: Alcatel-Lucent 1665 Dmxtend Optical Specifications
Alcatel-Lucent 1665 DMXtend optical specifications Overview Table 1-2 provides the optical specifications for Alcatel-Lucent 1665 DMXtend internal laser circuit packs; these packs do not use PTMs. Table 1-2 Alcatel-Lucent 1665 DMXtend optical circuit pack laser safety specifications Maximum Laser Circuit Pack Wavelength...
Page 32: Alcatel-Lucent 1665 Dmxtend Optical Ptm Laser Safety Specifications
Table 1-3 shows the pluggable transmission module (PTM) laser safety specifications and the supported circuit packs. The following Class 1 SFP/XFP transceivers are Alcatel- Lucent approved. Table 1-3 Alcatel-Lucent 1665 DMXtend optical PTM laser safety specifications Supported Maximum Max/Min Fiber...
Page 33 1310 -10.0/-18.0 SM (9) I(LN50)/1 IR1-I1 LNW84 (OC-3) 1310 0.0/-18.0 (OC-12/48) OC3X12X48 LNW55 1310 +3.0 -15.0/-2.0 SM (9) I(LN50)/1 LR1-I1 LNW84 (OC-3) 1310 +3.0 -9.0/-2.0 (OC-12/48) .................................................... 1 - 1 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 34 S622C51EL LNW37 1511 +5.0 -8.0/-28.0 SM (9) I(LN50)/1 LNW45 LNW49 LNW55 LNW84 LNW705 S622C53EL LNW37 1531 +5.0 -8.0/-28.0 SM (9) I(LN50)/1 LNW45 LNW49 LNW55 LNW84 LNW705 .................................................... 1 - 1 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 35 OC48SR1-I1 LNW41 1310 -3.0 -3.0/-18.0 SM (9) I(LN50)/1 LNW55 LNW62 LNW84 LNW402 LNW705 OC48LR1-I1 LNW41 1310 +3.0 -9.0/-27.0 SM (9) I(LN50)/1 LNW55 LNW62 LNW84 LNW402 LNW705 .................................................... 1 - 1 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 36 LNW84 LNW402 S2D33C6 LNW41 1550.918 +4.0 -9.0/-28.0 SM (9) I(LN50)/1 LNW55 LNW62 LNW84 LNW402 S2D35C6 LNW41 1549.315 +4.0 -9.0/-28.0 SM (9) I(LN50)/1 LNW55 LNW62 LNW84 LNW402 .................................................... 1 - 1 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 37 LNW84 LNW402 S2D55C6 LNW41 1533.465 +4.0 -9.0/-28.0 SM (9) I(LN50)/1 LNW55 LNW62 LNW84 LNW402 S2D59C6 LNW41 1530.334 +4.0 -9.0/-28.0 SM (9) I(LN50)/1 LNW55 LNW62 LNW84 LNW402 .................................................... 1 - 1 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 38 LNW84 LNW402 S2G7C57LI LNW41 1571 +5.0 -8.0/NA SM (9) I(LN50)/1 LNW55 LNW62 LNW84 LNW402 S2G7C59LI LNW41 1591 +5.0 -8.0/NA SM (9) I(LN50)/1 LNW55 LNW62 LNW84 LNW402 .................................................... 1 - 1 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 39 LNW141 1557.363 +3.0 SM (9) I(LN50)/1 8.0/Table 1 X10G26C5 LNW141 1556.555 +3.0 SM (9) I(LN50)/1 8.0/Table 1 X10G27C5 LNW141 1555.747 +3.0 SM (9) I(LN50)/1 8.0/Table 1 .................................................... 1 - 1 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 40 1535.036 +3.0 SM (9) I(LN50)/1 LNW603 8.0/Table 1 X10G54C5 LNW141 1534.250 +3.0 SM (9) I(LN50)/1 8.0/Table 1 X10G55C5 LNW141 1533.465 +3.0 SM (9) I(LN50)/1 8.0/Table 1 .................................................... 1 - 2 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 41: Dispersion-Limited Receiver Sensitivity For Oc-192 Dwdm Ptms
1300 ps/nm 1600 ps/nm Data Rate dispersion dispersion dispersion 9.9 Gb/s -24.0 dBm -22.0 dBm 10.7-11.1 Gb/s with -27.0 dBm -25.0 dBm Forward Error Correction (FEC) enabled .................................................... 1 - 2 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 42 Safety ......................................................................................................1 - 2 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 43 Overview Introduction Part I covers the physical mounting of the Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) shelf using the Horizontal Bay Mount. This section includes running and connecting power cables, interconnecting cables, alarm cables, and as required, external timing, and communication cables. Initial circuit pack installation (not seated) is also included.
Page 44: Part I: Physical And Power Installation
19" Mounting Brackets The 19" mounting brackets (C849011804) must be 849011804 ordered separately and are required to install the Alcatel-Lucent 1665 DMXtend in a 19" bayframe. Screwdriver(s) A screwdriver(s) with the appropriate head(s) is (are) required for securing the mounting screws,...
Page 45 2 or 3 LC-type Optical Fiber Two optical fiber jumpers with LC type connectors are Jumper ITE-7169 required to optically loop the Alcatel-Lucent 1665 (108918269) DMXtend shelf for test purposes. In addition, for shelves containing optical circuit packs in any of the function unit slots, a single optical fiber jumper is required for testing of the individual ports.
Page 46 † Registered trademark of Paladin Corporation. ® PC and cable requirements for WaveStar ® This section lists the required equipment needed to run the WaveStar CIT software with the Alcatel-Lucent 1665 DMXtend. Quantity Description Comments Personal Computer PC minimum requirements.
Page 47: Computer Requirements
750 MB. During installation, an additional 100 MB is required. To store a copy of an NE generic, another 125 MB is needed for each generic .................................................... I- 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 48: Installation Checklist
Procedure Required Part I: “Physical and power installation” Chapter 2, “Physical Inspection (p. 2-5) installation” Alcatel-Lucent 1665 DMXtend center divider See Note 1 (p. 2-5) Alcatel-Lucent 1665 DMXtend shelf installation (p. 2-8) Power cable installation (p. 2-13) Chapter 3, “Cable and fiber Inspection (p.
Page 49 LNW63 (GBE PL) 4 port or LNW64 (GBE PL) See Note 1 8-port installation (optional) (p. 4-20) LNW73/73C (4-Fiber channel See Note 1 FICON/ESCON) installation (optional) (p. 4- .................................................... I- 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 50 LNW43, LNW96 (apparatus blank) installation See Note 1 (optional) (p. 4-28) LNW42, LNW95 apparatus blank installation See Note 1 (optional) (p. 4-28) Notes: 1. Only required if equipped..................................................... I- 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 51: Physical Installation
Physical installation Overview Purpose This section provides equipment installation instructions for the Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) shelf using the horizontal bay mount configuration. The Alcatel-Lucent 1665 DMXtend shelves with the removable center divider can support either half width or full width cards in the Main function slots.
Page 52: Physical Installation
An ohmmeter is required to verify that the Alcatel- Lucent 1665 DMXtend is properly grounded. Mounting options The Horizontal Bay Mount mounting brackets on the Alcatel-Lucent 1665 DMXtend are designed to allow for mounting in the following: Standard 23-inch wide network bay frames •...
Page 53: Shelf Mount Rear Cover Kit 849001367
23-inch wide EIA-Type bay frames • Rear cover assembly This section describes the optional rear cover assembly kits for both Alcatel-Lucent 1665 DMXtend shelves, (Bay Mount Kit number 849001060) or Alcatel-Lucent 1665 DMXtend shelves (Shelf mount Kit number 849001367). Both kit assemblies will fit either the 19"...
Page 54: Cable Requirements And Options
The rear bay cover requires the front mounting configuration of the Alcatel- Lucent 1665 DMXtend shelf. This is mounting the shelf on the front of the bay with 5 inches of the shelf protruding from the front of the bay.
Page 55: Inspection
............................................Each Alcatel-Lucent 1665 DMXtend shelf comes with an installation kit. The bag containing the kit is attached inside the Alcatel-Lucent 1665 DMXtend shelf. The kit contains the following items: Quantity Description...
Page 56 New installation The procedure below describes how to remove the center dividers for new installations. Steps The figure below shows the new Alcatel-Lucent 1665 DMXtend shelf with the center dividers inserted. Note: The center dividers come equipped with a spring clip CC849027222 not shown in Figure 2-3, “Center divider”...
Page 57: Center Divider
Physical installation .................................................... Steps The figure below shows the Alcatel-Lucent 1665 DMXtend shelf with both center dividers inserted and a working circuit pack installed above the top divider. Figure 2-4 Center divider with circuit packs installed............................................Using a small flat screwdriver, separate the padding as shown in Figure 2-4, “Center...
Page 58: Alcatel-Lucent 1665 Dmxtend Shelf Installation
Positioning of the side brackets is also specified. Note: This section requires previous bay frame installation and grounding. Note: If the Alcatel-Lucent 1665 DMXtend shelf is to be used in an outside cabinet with no exchange of outside air, the air filter must be removed. Steps ............................................
Page 59 23-inch wide network bay frame with a 5 in. setback. The Alcatel-Lucent 1665 DMXtend shelf mounting brackets may have to be repositioned and remounted, depending on the frame type and mounting position (front or rear).
Page 60 Front 8.0 in. Rear Mount Left Side ............................................Determine the position that the Alcatel-Lucent 1665 DMXtend shelf will be mounted. Note: Start at the bottom of the bay and add shelves from bottom to top..................................................... 2 - 1 0 Alcatel-Lucent 1665 DMXtend R10.0...
Page 61: Fiber Duct Mounting
Figure 2-6 Fiber duct mounting ............................................Position the Alcatel-Lucent 1665 DMXtend shelf in the frame and secure the shelf to the frame using the thread-forming screws included with the shelf (3 screws per side). Tighten the screws to 21 in.-lb. (minimum)/30 in.-lb. (maximum).
Page 62: Safety Ground Screw
............................................If fiber spools are to be used, attach the spools to the Alcatel-Lucent 1665 DMXtend using the Fiber Spool Bracket Kit drawing 848949152. Attach the bracket to the shelf first and then the top fiber spool to the bracket. The lower fiber spool will need to overlap the top spool to snap into place.
Page 63: Power Cable Installation
.................................................... Figure 2-8 Fiber spools ............................................Verify with an ohmmeter that the Alcatel-Lucent 1665 DMXtend shelf is grounded to the bay frame. Measure between the Alcatel-Lucent 1665 DMXtend shelf mounting bracket and the office ground lug on the bay frame.
Page 64: Power Connection
CAUTION Verify that the BDCBB breakers are off or that the BDFB fuses are not installed............................................Splice feeders from the BDCBB or BDFB to the Alcatel-Lucent 1665 DMXtend power cable. See Table 2-3, “Power connections” (p. 2-16). and should be labeled as follows;...
Page 65 Chapter 4, “Circuit pack installation” of this manual............................................Check off the appropriate box in the Table I-2, Installation checklist. T E P S ..................................................................................2 - 1 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 66: Power Cable Assemblies
Pin # Cable Wire Designation Name BAT A -48VA BAT A -48RTNA BAT A RTN BAT B Blue -48VB BAT B -48RTNB BAT B RTN .................................................... 2 - 1 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 67: Final Operations
Verify that all power cables are properly labeled............................................Replace rear cover on shelf if ordered............................................Check off the appropriate box in the Table I-2, Installation checklist. T E P S ..................................................................................2 - 1 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 68 Physical installation ......................................................................................................2 - 1 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 69: Cable And Fiber Installation
Overview Purpose This section provides cabling instructions for the Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) shelf using the horizontal bay mount configuration. The Alcatel-Lucent 1665 DMXtend shelves with the removable center divider can support either half width or full width cards in the Main function slots.
Page 70: Planning
Stripper R-5648B D5 Replacement Paladin Cassette R-5648B D5 Wire-Wrap Gun R-4496A The wire-wrap gun is required for terminating DS1/E1 cable and must be able to accommodate 24 gauge wire..................................3 - 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 71: Cable Requirements And Options
DS1/DS3 Hybrid Optional Office Alarm Optional Office Alarm Mult Optional Miscellaneous Discrete Optional LAN 10BASE-T (Crossover) Optional LAN 10BASE-T (Straight Through) Optional Sync Timing Optional Modem Optional ..................................3 - 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 72: Connector References
Cable and fiber installation ..................................1. One CIT Cable Assembly is required for PC interface with the Alcatel-Lucent 1665 DMXtend (not included with equipment). 2. Two DS1/E1 Cable Assembly are required for each D or G function unit group that will support additional DS1/E1 traffic using the LNW8/801.
Page 73: Inspection
DB-25 female-type connector DB-62 male-type connector DB-62 female-type connector RJ-45 type connector Inspection Description Perform the following procedure before installing the Alcatel-Lucent 1665 DMXtend cables. Steps ..............................Inspect the shelf for visible damage including bent or touching backplane pins..................................
Page 74: Ds1/E1 Cable Installation
When cabling the Alcatel-Lucent 1665 DMXtend to a DSX, the DSX becomes an extension of the Alcatel-Lucent 1665 DMXtend backplane connections. Thus the IN on the Alcatel-Lucent 1665 DMXtend backplane connects to the IN of the DSX and the OUT of the Alcatel-Lucent 1665 DMXtend backplane connects to the OUT of the DSX respectively.
Page 75: Ds1/E1 Cable Connectors
Label the cables, indicating bay, shelf, function group (D or G) and direction (IN or OUT of the bay) at each end..............................Connect the function group cables at the Alcatel-Lucent 1665 DMXtend end, carefully matching the correct connector with the appropriate backplane connectors as shown in Figure 3-2, “DS1/E1 cable connectors” (p.
Page 76: Ds1/E1 Cable Routing To The Right
Route the cables along the cable rack and into the terminating bay..............................Remove slack and cut the DS1/E1 cables to the desired length at the DSX..................................3 - 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 77: Ds1/E1 Cable Assemblies
J2D (IN), DS1/E1 In (CA1) and 848548335 J4D (OUT) and J8G DS1/E1 Out (CA2) Cable 848923090 (IN), J10G (OUT) 848548343 848923108 848923116 848548350 848790762 848548368 848790770 848790788 ..................................3 - 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 78 DS1/E1 or DS3/EC-1 cabling. 5. Cables are terminated in J1D through J4D and J7G through J10G connectors at the Alcatel-Lucent 1665 DMXtend end and unterminated at the other end for wire-wrap installation. 6. The cable connectors are 62 pins D-Sub male-type connectors and fit into J1D through J4D and J7G through J10G.
Page 79: Ds1 Transmission Connections
3 (19) B4/B3 Y/BR 7/28 4 (20) B2/B1 6/27 1 (21) B8/B7 V/BL 48/47 2 (22) B6/B5 5/26 3 (23) B4/B3 46/45 4 (24) B2/B1 V/BR 4/25 ..................................3 - 1 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 80 3 (47) B4/B3 Y/BR 7/28 4 (48) B2/B1 6/27 1 (49) B8/B7 V/BL 48/47 2 (50) B6/B5 5/26 3 (51) B4/B3 46/45 4 (52) B2/B1 V/BR 4/25 ..................................3 - 1 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 81: Ds3/Ec-1 Cable Installation
Alcatel-Lucent 1665 DMXtend backplane connections. Therefore, the IN on the Alcatel-Lucent 1665 DMXtend backplane connects to the IN of the DSX and the OUT of the Alcatel-Lucent 1665 DMXtend backplane connects to the OUT of the DSX respectively DS3/EC-1 cable options are listed in Table 3-4, “DS3/EC-1 cable assemblies”...
Page 82 48) are cabled to the center connectors of the shelf (J2D, J4D, J8G, and J10G)..............................Connect the function group cables at the Alcatel-Lucent 1665 DMXtend end, carefully matching the correct connector with the appropriate backplane connectors as shown in Figure 3-5, “DS3/EC-1 cable connections”...
Page 83: Ds3/Ec-1 Cable Connections
Figure 3-6 DS3/EC-1 cable routing to the right Notes: The 12-conductor DS3/EC-1 cable is showing that this cable could be either the 12- or 24-conductor DS3/EC-1 cable..................................3 - 1 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 84: Ds3/Ec-1 Cable Routing To The Left
There is no issue interchanging these cables on the backplane. The DS3/EC-1 Signals are common between both cables..............................Check off the appropriate box in the Table I-2, Installation checklist..................................3 - 1 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 85: Ds3/Ec-1 Cable Assemblies
Plug Kit KINGS 75ohm 734D 848965786 cable type (12)BNC Plug Kit TROMPETER 848965794 75ohm 735A cable type (12)BNC Plug TROMPETER 848965802 75ohm 734D cable type (12)BNC Plug ..................................3 - 1 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 86 J1D (IN), J3D 848940045 Cable DS3/EC-1 Out (OUT) and J7G (IN), J9G (CA2) Cable 848940052 (OUT) 848940060 848940078 848940086 848940094 848940102 848940110 848940128 848940136 848940144 848940151 ..................................3 - 1 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 87 J1D (IN), J3D 849041132 shipped loose. (OUT) and J7G (IN), J9G 849041140 (OUT) See below for different vendors’ 849041157 BNC Plug Kits. 849041165 849041173 849041181 849041199 ..................................3 - 1 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 88 735A/734 Splice 849041983 735A/734 Splice 849041991 735A/734 Splice NE to NE 849042007 735A/734 Splice NE to NE These kits include 25/50 individually bagged BNCs w/ assembly instructions ..................................3 - 2 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 89 734D cable type (24)BNC Plug Kit ITT CANON 75ohm 409013562 735A cable type (50)BNC Plug Kit ITT CANON 75ohm 409013570 734D cable type (50)BNC Plug Kit ..................................3 - 2 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 90 G DS3 (24PK) Cable 849041801 735/734 Splice Assembly 849041819 735/734 Splice 849041827 735/734 Splice 849041835 735/734 Splice 849041843 735/734 Splice 849041850 735/734 Splice 849041868 735/734 Splice ..................................3 - 2 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 91 849040985 849040993 849041009 849041017 849041025 849041033 849041041 849041066 849041074 Ne to Ne Only 849041082 Ne to Ne Only 849041090 Ne to Ne Only 848932083 735A/734 Splice ..................................3 - 2 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 92: Twenty-Four Cable Ds3/Ec-1 Transmission Connections
4. For Input connections use cable CA1 (DS3/EC-1 IN) and for Output connections use cable CA2 (DS3/EC-1 OUT). 5. 735A cable is used to connect Alcatel-Lucent 1665 DMXtend to DSX-3 or another NE (10 to 450 ft. length). 6. The cable connectors are 62 pins D-Sub male-type connectors and fit into J1D through J4D and J7G through J10G.
Page 93 Ground DS3 10R/10T Signal FRG10 Ground DS3 11R/11T Signal FRG11 Ground DS3 12R/12T Signal FRG12 Ground DS3 13R/12T Signal FRG13 Ground DS3 14R/12T Signal FRG14 Ground ..................................3 - 2 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 94 J2D (IN), J4D (OUT) and J8G (IN), J10G (OUT) This Cable Routes to the Left. DS3 25R/12T Signal FRG25 Ground DS3 26R/12T Signal FRG26 Ground DS3 27R/12T Signal FRG27 Ground ..................................3 - 2 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 95 Ground DS3 37R/12T Signal FRG37 Ground DS3 38R/12T Signal FRG38 Ground DS3 39R/12T Signal FRG39 Ground DS3 40R/12T Signal FRG40 Ground DS3 41R/12T Signal FRG41 Ground ..................................3 - 2 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 96: Twelve Cable Ds3/Ec-1 Transmission Connections
J1D (IN), J3D (OUT) and J7G (IN), J9G (OUT) This Cable Routes to the Right. DS3 1R/1T Signal FRG1 Ground DS3 2R/2T Signal FRG2 Ground DS3 3R/3T Signal FRG3 Ground ..................................3 - 2 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 97 Lead designation for EC-1 connection for cable# x should be read as EC1 xR/xT instead of DS3 xR/xT, where x is a number from 1 to 12..................................3 - 2 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 98 This section describes how to connect the DS1 and DS3 Hybrid cables to the Alcatel- Lucent 1665 DMXtend shelf and route the cables out of the bay and to the DS1 and DS3 Hybrid Cable terminating equipment. Perform this procedure if DS1 and DS3 Hybrid cables are required.
Page 99: Ds1 And Ds3 Hybrid Cable Connections
(DSX-3 or other terminating transmission equipment)..............................Cut the coaxial cables to desired length and install the BNC connectors shipped with the cable assemblies..................................3 - 3 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 100: Ds1 And Ds3 Hybrid Cable Ds1 Transmission Connections
3-35), carefully observe color codes and wire-wrap the cables at the DSX..............................Check off the appropriate box in the Table I-2, Installation checklist. T E P S ................................................................3 - 3 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 101: Ds1 And Ds3 Hybrid Cable Assemblies
DS3 is 849006960 short and staggered for 849006978 interbay use. 849006986 849006994 849007000 The following kits include 13 individually bagged BNCs with instructions: ..................................3 - 3 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 102 7. For the Coaxial cable the longest distance allowed to connect Alcatel-Lucent 1665 DMXtend to another NE is 450ft. of length. The 550 and 655 ft. cables are for the DS1 cables only and the Coaxial cable must be terminated at 450 ft.
Page 103: Ds1 And Ds3 Hybrid Cable Ds3 Transmission Connections
54/53 BK/O 12/33 4 (12) B2/B1 1 (13) B8/B7 BK/G 11/32 2 (14) B6/B5 BK/BR 10/31 3 (15) B4/B3 BK/S 52/51 4 (16) B2/B1 Y/BL 9/30 ..................................3 - 3 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 104: 10/100Base-T Ethernet Cable Installation
Description This section describes how to connect the 10/100BASE-T cables to the Alcatel-Lucent 1665 DMXtend shelf and route the cables out of the bay and to the 10/100BASE-T terminating equipment. Perform this procedure if 10/100BASE-T cables are required. This section describes how to route the 10/100BASE-T cables from the interconnecting equipment (for example, a 110/RJ45 punch down block) to the Alcatel-Lucent 1665 DMXtend backplane.
Page 105: 10/100Base-T Cable Routing
J2D, J4D, J8G, and J10G difficult, but there are currently no plans to use these connectors in a 10/100BASE-T application. Figure 3-11 10/100BASE-T cable routing ..............................Route the cables along the cable rack and into the terminating bay..................................3 - 3 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 106 Description assembly # (feet) connections 10/100BASE-T/TX 848819090 J1D, J3D, J7G, and Ethernet cable 848778114 848923280 848778122 848923298 848778106 848923306 848778148 848923314 848923322 848923330 848923348 848923355 848778130 ..................................3 - 3 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 107 R+/R- Y/BR 16/37 T+/T- 60/59 R+/R- V/BL 17/38 T+/T- V/BR 15/36 R+/R- 14/35 T+/T- Notes: 10/100BASE-T/TX ethernet cables have transmit and receive on the same cable..................................3 - 3 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 108: Ethernet Cabling To Sfp Modules On Circuit Pack Faceplates
849010483 CAT5e Gigabit ethernet shielded connectorized on both ends with straight RJ45 connector. 849010491 849010509 849010525 849010558 849010608 849010657 849010681 849010731 T E P S ................................................................3 - 4 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 109: Iao Lan And Tcp/Ip Cable Installation
3-44)]..............................If connecting to the front of the Alcatel-Lucent 1665 DMXtend shelf, connect the cable to the LAN (RJ45) jack on the SYSCTL circuit pack. If connecting to the rear of the Alcatel-Lucent 1665 DMXtend shelf, connect the cable to the J17 port (IAO LAN) on the Alcatel-Lucent 1665 DMXtend backplane and route to the left side of the shelf.
Page 110: Lan 10Baset Cable Assemblies
Cable and fiber installation ..................................Figure 3-12 IAO LAN/TCP-IP cable connection to rear of Alcatel-Lucent 1665 DMXtend ..............................If a cross-over cable is used, route the cable to the desired PC LAN port. If a straight-through cable is used, route the cable to the desired hub port location.
Page 111 Ethernet hub 109321844 / router 109321851 848604948 109321869 109321877 109321885 109321893 848604955 109321901 109321919 109321927 109321935 848604963 109321943 109321950 848604971 109321968 109321976 109321984 109321992 848604997 ..................................3 - 4 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 112: Modem Cable Installation
Table 3-16, “Modem cable assemblies” (p. 3-45). Connect the RJ45 end of the modem cable to the MODEM port (J18) of Alcatel-Lucent 1665 DMXtend shelf and route it to the left side of the shelf. (See Figure 3-13, “Modem cable connection”...
Page 113: Modem Cable Assemblies
Cable and fiber installation ..................................Figure 3-13 Modem cable connection ..............................Route the modem cable out of the Alcatel-Lucent 1665 DMXtend bay to the modem or distribution frame..............................Dress and tie the modem cable to the Alcatel-Lucent 1665 DMXtend backplane per Figure 3-13, “Modem cable connection”...
Page 114: Sync Cable Installation
The section provides the instructions for installing the two types of synchronization (Sync) cables to the Alcatel-Lucent 1665 DMXtend. A Sync cable is required if the shelf is to be externally timed. The Alcatel-Lucent 1665 DMXtend can provide DS1 external timing to a BITS clock. When the shelf is externally timed by a DS1 Reference and/or is configured to provide a Sync Output, a Sync Input timing cable is required.
Page 115: Sync Cable Connections
Perform the following steps when using a Sync cable with a molded DB-9 connector..............................Connect the DB-9 connector end of the Sync cable to the SYNC1 (J11) port on the Alcatel-Lucent 1665 DMXtend backplane. See Figure 3-14, “Sync cable connections” 3-47).
Page 116 Step 1 through Step 5 for SYNC2 (J12) connection..............................Check off the appropriate box in the Table I-2, Installation checklist. T E P S ................................................................3 - 4 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 117 Note: The Sync cable is 22 gauge. Ground the Filter connectors either at the bay frame ground or at the office timing source. See office records..................................3 - 4 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 118: Office Alarm Cable Installation
3-53). Alarm mult Office alarm cabling in a Alcatel-Lucent 1665 DMXtend bay starts at the bottom shelf which is cabled directly to the office alarm system. Then as shelves are added to the bay, the office alarm connection is extended by multing the alarm cabling from shelf to shelf (bottom to top).
Page 119: Office Alarm Cable Connections
Figure 3-15, “Office alarm cable connections” (p. 3-51). Figure 3-15 Office alarm cable connections ..............................Route the office alarm cable from the bottom shelf out of the Alcatel-Lucent 1665 DMXtend bay per Figure 3-16, “Office alarm cable routing” (p. 3-51) to the office alarm panel.
Page 120 No shelf should be skipped..............................Obtain the office alarm mult cable 848589602 for Alcatel-Lucent 1665 DMXtend. Connect one end to ALM MULT (J14) of the Alcatel-Lucent 1665 DMXtend shelf. See Figure 3-15, “Office alarm cable connections” (p. 3-51).
Page 121: Office Alarm Cable Assemblies
1. The SYSCTL circuit pack reports office alarms. 2. The connection to the central office alarms from P13 is run for each Alcatel- Lucent 1665 DMXtend shelf assembly when used in a miscellaneously mounted individual application or from the first Alcatel-Lucent 1665 DMXtend shelf assembly when mounted in a typical bay arrangement.
Page 122: Miscellaneous (Environmental) Discrete Telemetry Cable Installation
Description The miscellaneous (environmental) discrete telemetry access allows the maintenance center to control and monitor equipment collocated with the Alcatel-Lucent 1665 DMXtend. The environmental control feature enables the maintenance center to remotely initiate up to four contact closures at the remote terminal (RT) for equipment operation such as pumps, generators, etc.
Page 123: Miscellaneous Discrete Cable Connection
Cable and fiber installation ..................................Figure 3-17 Miscellaneous discrete cable connection ..............................Route the cable out of the Alcatel-Lucent 1665 DMXtend bay per Figure 3-18, “Miscellaneous discrete cable routing” (p. 3-55) to the telemetry panel. Figure 3-18 Miscellaneous discrete cable routing ..............................
Page 124 For each output, one lead should be connected to output-common and the other lead should be connected to the appropriate alarm indication..............................Check off the appropriate box in the Table I-2, Installation checklist. T E P S ................................................................3 - 5 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 125: Miscellaneous Discrete Cable Assemblies
R-BL TLMI12 Env. Input - #12 TLMI13 Env. Input - #13 TLMI14 Env. Input - #14 TLMI15 Env. Input - #15 TLMI16 Env. Input - #16 ..................................3 - 5 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 126: Oc-3/Oc-12/Oc-48/Oc-192 Main Optical Fiber Cable Installation
12/OC-48/OC-192 Main OLIUs of the Alcatel-Lucent 1665 DMXtend. This procedure does not cover routing the optical fiber cable between sites. The optical fiber cables will be connected to the Alcatel-Lucent 1665 DMXtend after the circuit packs are installed. The Alcatel-Lucent 1665 DMXtend requires single-mode fiber for the main OLIUs.
Page 127 Steps ..............................Route the optical fiber cables from the interconnecting equipment into the left side of the Alcatel-Lucent 1665 DMXtend. See Figure 3-19, “Optical fiber routing” (p. 3-60). Note: Protective covers must be left on cables.
Page 128: Optical Fiber Routing
Label the optical fiber cables, indicating bay, shelf, pack, and direction (IN or OUT). See Appendix E, “Fiber labeling” for more details..............................Check off the appropriate box in the Table I-2, Installation checklist. T E P S ................................................................3 - 6 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 129: Oc-3/Oc-12/Oc-48 Low-Speed Optical Fiber Cable Installation
PVC tubing, or PANDUIT cable channel, when running the cable from the Alcatel-Lucent 1665 DMXtend to the cable rack. The fibers should be placed in the cable rack in a protective channel with nothing on top of them.
Page 130: 100/1000Base-X Optical Fiber Cable Installation
PVC tubing, or PANDUIT cable channel, when running the cable from the Alcatel-Lucent 1665 DMXtend to the cable rack. The fibers should be placed in the cable rack in a protective channel with nothing on top of them.
Page 131 Label the optical fiber cables, indicating bay, shelf, function group, pack, and direction (IN or OUT)..............................Route optical fiber cables from the interconnecting equipment into the left side of the Alcatel-Lucent 1665 DMXtend and into the 100/1000BASE-X optical ports. See Table 3-19, “Optical fiber routing” (p. 3-60)..............................
Page 132: Cit (Rs-232) Cable Installation
Table 3-24 CIT Cable Assembly Alcatel-Lucent 1665 Cable Cable DMXtend Description assembly # length connections Front CIT 848748869 8 feet CIT/RS-232 jack on System cable Controller (LNW2) ..................................3 - 6 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 133: Standard Cit Cable Connection
FRXD Transmit Data Notes: 1. The connection and the colors shown above are for a standard Alcatel-Lucent made cable. If you use a RJ-45 to DB-9 connector with a standard straight- through 10BASE-T LAN cable then, see Table 3-26, “RJ-45 to DB-9 connector connections”...
Page 134: Final Operations
Verify that designations where fibers were terminated are properly labeled..............................Replace rear cover on shelf if ordered..............................Check off the appropriate box in the Table I-2, Installation checklist. T E P S ................................................................3 - 6 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 135: Circuit Pack Installation
• Circuit pack option settings and installation. • Detailed information on the function of each circuit pack is contained in Alcatel-Lucent 1665 Data Multiplexer Extend (DMXtend) Applications and Planning Guide, 365-372- Contents This chapter provides information on the following topics:...
Page 136: Powering
PC to the CIT jack on the front of the SYSCTL circuit pack. Powering Overview The following table lists the requirements for the Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) shelf. Table 4-1 Alcatel-Lucent 1665 DMXtend shelf power supply requirements Item...
Page 137 (one per feeder) Steps ............................................Verify that the frame or structure into which the Alcatel-Lucent 1665 DMXtend Shelf is installed is properly grounded............................................Verify that both 10 ampere circuit breakers on the Alcatel-Lucent 1665 DMXtend are in the OFF position.
Page 138: Power Connections On Alcatel-Lucent 1665 Dmxtend Backplane
............................................If breakers are being used, verify that 25-ampere breakers are installed and switch the breakers to the ON position for the Alcatel-Lucent 1665 DMXtend A and B feeders............................................At the Alcatel-Lucent 1665 DMXtend power cable connector, use a voltmeter and measure the voltage on the power cable between BAT A and BAT A RTN.
Page 139 Alcatel-Lucent 1665 DMXtend, in the ON position............................................Verify that the both the PWR A LED and PWR B LED on the Alcatel-Lucent 1665 DMXtend user panel are lighted with both the “A” and “B” feeds powered............................................
Page 140: Circuit Pack Compatibility
Table 4-2, “R10.0circuit pack slot compatibility” (p. 4-6) lists all the circuit packs that are compatible with R10.0 and their respective shelf locations (slots). Figure 4-8, “Alcatel-Lucent 1665 DMXtend shelf” (p. 4-9) for slot locations. Table 4-2 R10.0circuit pack slot compatibility...
Page 141 LNW141 LNW141 LNW170 LNW170 LNW302 LNW382 LNW391 LNW402 LNW402 LNW601 LNW603 LNW603 LNW705 LNW785 LNW785 LNW801 LNW801 LNW8/ LNW8/ LNW801 LNW801 LNW910 LNW910 177D 177D LNW43 LNW42 .................................................... 4 - 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 142 Table 4-3 OC-3 mains with 6 STS-1s of vt switch fabric OC-3 Circuit packs LNW40 LNW149 LNW601 LNW302 Table 4-4 OC-12 mains with 12 STS-1s of vt switch fabric OC-12 Circuit packs LNW38 LNW51 LNW382 .................................................... 4 - 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 143: Initial Circuit Pack Installation
Alcatel-Lucent 1665 DMXtend shelf. After circuit packs have been unpacked, they may be placed in their respective slots in the Alcatel-Lucent 1665 DMXtend shelf but not fully engaged in the backplane connector. The circuit packs will be fully installed (seated) in the next section.
Page 144 “Alcatel-Lucent 1665 DMXtend shelf” (p. 4-9)............................................Place the SYSCTL circuit pack into the CTL slot on the Alcatel-Lucent 1665 DMXtend shelf. Do NOT engage the circuit pack in the backplane connector............................................Check off the appropriate box in the “Installation checklist”...
Page 145 Lucent 1665 DMXtend shelf” (p. 4-9)............................................Place the main OLIU circuit pack into the M1 slot on the Alcatel-Lucent 1665 DMXtend shelf. Do NOT engage the circuit pack in the backplane connector............................................Remove the second main OLIU from the packing material.
Page 146 LNW7 (28DS1PM) and LNW8/LNW801 (56DS1E1) installation (optional) Follow this procedure only if installing LNW7 (28DS1PM) or LNW8/LNW801 (56DS1E1) circuit packs into the Alcatel-Lucent 1665 DMXtend shelf. Note: The LNW7 is not supported when the LNW141 or LNW84 VLF main OLIU is used.
Page 147 ................................ LNW16 (12DS3/EC1) and LNW19B (48DS3/EC1) installation (optional) Follow this procedure only if installing LNW16 (12DS3/EC1) or LNW19B (48DS3/EC1) circuit packs into the Alcatel-Lucent 1665 DMXtend shelf............................................See the engineering job specification. Identify the proper function group(s) where LNW16 or LNW19B will be installed.
Page 148 ................................ LNW18 (12TMUX) and LNW20 (48TMUXDS3EC1) installation (optional) Follow this procedure only if installing LNW18 (12TMUX) or LNW20 (48TMUXDS3EC1) into the Alcatel-Lucent 1665 DMXtend shelf............................................See the engineering job specification. Identify the proper function group(s) where LNW18 or LNW20 will be installed.
Page 149 ................................ LNW31 (OC-48 OLIU) low-speed installation (optional) Follow this procedure only if installing LNW31 (OC-48 OLIU) circuit packs into the Alcatel-Lucent 1665 DMXtend shelf............................................See the engineering job specification. Identify the proper function group(s) and/or growth slot(s) where LNW31 circuit pack will be installed.
Page 150 Follow this procedure if installing the LNW37 (OC-3 4 port PTM OLIU), LNW45 (OC-3 8 port PTM OLIU), or LNW603 (OC-192 PTM OLIU) circuit packs into the Alcatel- Lucent 1665 DMXtend shelf. Note: The LNW37, LNW45, and LNW603 circuit pack comes in separate boxes, with one box containing the circuit pack, and the other containing the ordered quantity of PTMs.
Page 151 LNW39/LNW391 (DS1/DS3/16/3), LNW111 (3DS3) and LNW112 (16DS1) installation (optional) Follow this procedure only if installing LNW39/LNW391 (DS1/DS3/16/3), LNW111 (3DS3) or LNW112 (16DS1) circuit packs into the Alcatel-Lucent 1665 DMXtend shelf. Note: The LNW39, LNW391, LNW111 and LNW112 are not supported when the LNW141 or LNW84 VLF main OLIU is used.
Page 152 LNW49 (OC-12 4 port PTM OLIU) low-speed installation (optional) Follow this procedure only if installing the LNW49 (OC-12 4 port PTM OLIU) circuit packs into the Alcatel-Lucent 1665 DMXtend shelf. Note: The LNW49 (OC-12 4 port PTM OLIU) circuit pack comes in separate boxes, with one box containing the circuit pack, and the other containing the ordered quantity of PTMs.
Page 153 LNW62 (4 OC-48 PTM OLIU) or LNW55 (OC-3/OC-12/OC-48 12/4 port OLIU) low speed installation (optional) Follow this procedure only if installing the LNW62 (4 OC-48 PTM OLIU) or LNW55 (OC-3/OC-12/OC-48 12/4 PTM OLIU) circuit packs into the Alcatel-Lucent 1665 DMXtend shelf. Note:...
Page 154 LNW63 or LNW64 circuit pack will be installed. Note: LNW63 or LNW64 circuit pack can only be installed in slot 1 of any function group unless the LNW141 or LNW84 VLF main OLIU is used. See Alcatel-Lucent .................................................... 4 - 2 0 Alcatel-Lucent 1665 DMXtend R10.0...
Page 155 Note: LNW73/73C circuit pack can only be installed in slot 1 of any function group unless the LNW141 or LNW84 VLF main OLIU is used. See Alcatel-Lucent 1665 Data Multiplexer Extend (DMXtend) Applications and Planning Guide, 365-372-324 for allowed combinations.
Page 156 LNW74 (10/100T/F), LNW87 (FE/GBE PL), or LNW910 (FE/GBE/10GBE) installation (optional) FE/GBE PL), or Follow this procedure if installing an LNW74 (10/100T/F), LNW87 ( LNW910 (FE/GBE/10GBE) circuit pacs in the Alcatel-Lucent 1665 DMXtend shelf. Note: The LNW74, LNW87, or LNW910 circuit packs require PTM modules for the Ethernet interface.
Page 157 Check off the appropriate box in the “Installation checklist” (p. I-6). T E P S ................................ LNW170 (100/1G FXS) Follow this procedure only if installing LNW170 circuit packs into the Alcatel-Lucent 1665 DMXtend shelf..................................................... 4 - 2 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1...
Page 158 ................................ LNW402 OC48 1310 nm, 1550 nm, or DWDM PTM Optics Follow this procedure to install the LNW402 circuit packs in the Alcatel-Lucent 1665 DMXtend shelf. The high-speed LNW402 is a single-port OLIU that employs PTM pluggable optics to offer 1310 nm, 1550 nm, or DWDM optics with a 12 STS-1 VT fabric.
Page 159 ................................ LNW705 XM10G/8 muxponder pack Follow this procedure to install a LNW705 circuit pack in an Alcatel-Lucent 1665 DMXtend. The LNW705 XM10G/8 circuit pack multiplexes/demultiplexes up to 8 ports onto a single 10G wavelength. The LNW705 XM10G/8 circuit pack provides transport for...
Page 160 T E P S ................................ LNW785 OMD5/8 8-channel low-loss DWDM optical mux/demux Follow this procedure to install the LNW785 circuit packs in the Alcatel-Lucent 1665 DMXtend shelf. The LNW785 OMD5/8 circuit pack multiplexes/demultiplexes up to 8 DWDM optical channels. Note:...
Page 161 ................................ 177D, LNW98 (Apparatus Blank) installation (optional) Follow this procedure to install 177D or LNW98 Apparatus Blank(s) into the Alcatel- Lucent 1665 DMXtend shelf. Note: 177D or LNW98 Apparatus Blanks are required in all unused slots D and G to provide proper air flow for cooling.
Page 162 ................................ LNW43, LNW96 (apparatus blank) installation (optional) Follow this procedure to installs LNW43 or LNW96 Apparatus Blank(s) into the Alcatel- Lucent 1665 DMXtend shelf. Note: A LNW43 or LNW96 Apparatus Blank is required in any unequipped A1/B1 or A2/B2 slots to provide proper air flow for cooling.
Page 163 Do NOT engage the blank pack in the backplane connector............................................Check off the appropriate box in the “Installation checklist” (p. I-6). T E P S ..................................................................................4 - 2 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 164 Circuit pack installation ......................................................................................................4 - 3 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 165: Part Ii: Stand-Alone Installation Tests
“Installation checklist” to follow when installing a Alcatel-Lucent 1665 DMXtend system. Use of the installation checklist is required to ensure a quality installation. All completed tasks should be checked off and those not completed should be duly noted as to the reason why. This checklist should be turned in as part of your job complete paperwork.
Page 166 2 or 3 LC-type Optical Fiber Two optical fiber jumpers with LC type connectors are Jumper ITE-7169 required to optically loop the Alcatel-Lucent 1665 (108918269) DMXtend shelf for test purposes. In addition, for shelves containing optical circuit packs in any of the function unit slots, a single optical fiber jumper is required for testing of the individual ports.
Page 167 15-dB LC-type LBO ITE- LBOs are only required when optically looping the 7196 (108279480) Alcatel-Lucent 1665 DMXtend shelves containing optical circuit packs in any of the function unit slots; a single 15-dB LBO is required for testing of the individual ports Noyes OFS 300-200X This equipment may not be necessary at all locations.
Page 168 Stand-alone installation tests .................................................... ® PC and cable requirements for WaveStar ® This section lists the required equipment needed to run the WaveStar CIT software with the Alcatel-Lucent 1665 DMXtend. Quantity Description Comments Personal Computer PC minimum requirements. (PC) RS-232 Interface 8-ft.
Page 169 ® “Use of WaveStar CIT software” (p. 5-6) “Steps” (p. 5-6) “Circuit pack program version verification” (p. 5-12) “Alcatel-Lucent 1665 DMXtend shelf initialization” (p. 5-13) Chapter 6, “Stand-alone “LBO software settings” (p. 6-4) See Note 1 installation testing” “Clearing alarms” (p. 6-7) See Note 1 “Local equipment and cross-connect tests”...
Page 170 “Miscellaneous (environmental) discrete See Note 1 telemetry test” (p. 6-55) “Modem connection test” (p. 6-59) See Note 1 “Final operations” (p. 6-61) Notes: 1. Only required if equipped..................................................... II - 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 171: Stand-Alone Node Setup
Software installation Circuit pack installation ® Use of WaveStar CIT software Circuit pack program version verification 5-12 Alcatel-Lucent 1665 DMXtend shelf initialization 5-13 Tools, test equipment and accessories Listed below are the required tools, test equipment and accessories. Quantity Description Comments ®...
Page 172: Stand-Alone Node Setup
Software installation CIT software installation is accomplished by performing the “Installing software and documentation on a PC” section in the Alcatel-Lucent 1665 Data Multiplexer Extend (DMXtend) Release 9.1.0 Software Release Description which is shipped with the software CD. When the software installation is complete, check off the appropriate box in “Installation checklist”...
Page 173: Circuit Pack Installation
Description This section provides instructions and the recommended order for installing (fully seating) the circuit packs in the Alcatel-Lucent 1665 DMXtend shelf. The procedures in this section assume that the SYSCTL is installed and operational. Locations of circuit packs (function unit slots) are shown in Figure 4-8, “Alcatel-Lucent...
Page 174 Appendix B, “PTM modules” for proper insertion..............................Connect IN to OUT on the OLIU in the M1 slot of the Alcatel-Lucent 1665 DMXtend shelf using an optical fiber jumper cable and a 15-dB LBO. See Appendix A, “Fiber cleaning”...
Page 175 Stand-alone node setup ..................................Connect IN to OUT on the OLIU in the M2 slot of the Alcatel-Lucent 1665 DMXtend shelf using an optical fiber jumper cable and a 15-dB LBO. CAUTION Equipment damage The LNW38, LNW40, LNW51, LNW302, LNW382, and LNW601 OLIU circuit packs are equipped with optics that do not meet GR-78 R9-3 requirements on ESD susceptibility.
Page 176: Use Of Wavestar ® Cit Software
® Use of WaveStar CIT software Description Complete the following steps to login to the Alcatel-Lucent 1665 DMXtend via ® WaveStar CIT. It is assumed that the CIT software has been installed on the PC and the LNW2 system controller is installed and operational to the Alcatel-Lucent 1665 DMXtend shelf per the Alcatel-Lucent 1665 Data Multiplexer Extend (DMXtend) Release 9.1.0...
Page 177 ® Start the WaveStar CIT software on the PC by double clicking on the WaveStar icon that was created by the installation procedure. The following windows appear: ..................................5 - 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 178 When the CIT is installed, there is an optional step to enable or disable CIT logins. This screen shot would not be displayed if the user chose to disable CIT logins..............................Click to connect. The screen appears: ..................................5 - 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 179 DHCP, the SYSCTL will provide the PC with an IP address within a minute or so. Connection through TCP/IP is now possible using the default IP address of 169.254.1.1..................................5 - 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 180 NE login screen appears..............................Enter the Login information (case sensitive)for the shelf: LUC01 User ID: Password DMXTND2.5G Click and the NE legal notice appears..................................5 - 1 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 181 Familiarize yourself with different aspects of the Graphical presentation of a shelf including tool bars and menu bars..............................Check off the appropriate box in the “Installation checklist” (p. II-5). T E P S ................................................................5 - 1 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 182: Circuit Pack Program Version Verification
SYSCTL is installed and the circuit packs have been installed in the shelf as described in the preceding sections. Steps ..............................Log on to the Alcatel-Lucent 1665 DMXtend shelf using the CIT software as described in ® “Use of WaveStar CIT software” (p.
Page 183: Alcatel-Lucent 1665 Dmxtend Shelf Initialization
The procedures in this section assume that the SYSCTL is installed and the circuit packs have all been installed in the shelf as described in the preceding sections. Steps ..............................Log on to the Alcatel-Lucent 1665 DMXtend shelf using the CIT software as described in ® “Use of WaveStar CIT software” (p.
Page 184 Stand-alone node setup ....................................................................5 - 1 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 185: Stand-Alone Installation Testing
Purpose The purpose of this section is to verify proper transmission cabling installation and R10.0 functionality as well as the associated functionality of the Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) shelf. For end-to-end turn-up and testing procedures, see Alcatel-Lucent 1665 Data Multiplexer Extend (DMXtend) User Operations Guide, 365-372-325.
Page 186 Stand-alone installation testing .................................................... External timing verification 6-52 Miscellaneous (environmental) discrete telemetry test 6-55 Modem connection test 6-59 Final operations 6-61 .................................................... 6 - 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 187 848748869). Required to connect the PC to the CIT jack on the front of the SYSCTL circuit pack. LAN 10BaseT As required to reach from front of Alcatel-Lucent 1665 Straight-through DMXtend to the RJ45 patch panel Cable CAT 5 or better ....................................................
Page 188: Lbo Software Settings
DS1/E1 and DS3/EC1 cabling. The SYSCTL, DS1/E1 and/or DS3/EC1 circuit packs must be installed and software must be loaded. Follow this procedure to set the LBOs for the DS1/E1, DS1/DS3/16/3, DS3/EC1, and TMUX circuit packs..................................................... 6 - 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 189 Stand-alone installation testing .................................................... Setting DS1/E1 LBOs ............................................Log on to the Alcatel-Lucent 1665 DMXtend shelf using the CIT software as described in ® “Use of WaveStar CIT software” (p. 5-6)............................................See the following table of cable lengths and LBO values. Determine the LBO value corresponding to the DS1/E1 cables installed.
Page 190 All DS3 ports will have a LBO value of In for this pack............................................Check off the appropriate box in the “Installation checklist” (p. II-5). T E P S ..................................................................................6 - 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 191: Clearing Alarms
Clearing alarms Description In order to clear standing alarms the Alcatel-Lucent 1665 DMXtend synchronization will be optioned for “Free Running.” The DCC will be disabled in order to prevent DCC alarms from being generated due to the optical loopback on the main OLIUs.
Page 192: Local Equipment And Cross-Connect Tests
Chapter 4, “Circuit pack installation” is complete and the Alcatel- Lucent 1665 DMXtend shelf has fiber loopback cables on the Main OLIUs, with Far-End Communication disabled and synchronization set to free-running. On initial installation/turn-up of Alcatel-Lucent 1665 DMXtend, there are no default cross-connects.
Page 193: Ds1/E1 Testing
DS1/E1 testing DS1/E1 testing procedure Perform the following steps for all Alcatel-Lucent 1665 DMXtend shelf function unit slots that are cabled to a DSX-1. Function unit slot A/B must be cabled to the DSX-1 and must contain a DS1/DS3/16/3 (LNW39/LNW391/LNW84), 16/DS1 (LNW112) or OC-3/16DS1 (LNW40) circuit pack in order to perform these tests on the DS1/E1 portion of the cabling.
Page 194 Select m1-1-1-1-1 to a1-1-1-1 (if using a combo card) or [d,g] if using the function slots............................................Click Finish to issue the command. Result: The DS-1 test set should indicate it is receiving an error free QRSS signal with B8ZS formatting..................................................... 6 - 1 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 195 (OC-N). Click on the ............................................Double click on port 1 (OC-N)............................................Select Next............................................Select Next............................................Select Finish............................................Click Yes............................................Click Yes..................................................... 6 - 1 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 196 DS-1 tributaries of the function unit, substituting the following address information. Tributary @ DSX-1 Cross-connect m1-1-1-1-2,a1-1-1-2 m1-1-1-1-3,a1-1-1-3 m1-1-1-1-4,a1-1-1-4 m1-1-1-2-1,a1-1-2-1 m1-1-1-2-2,a1-1-2-2 m1-1-1-2-3,a1-1-2-3 m1-1-1-2-4,a1-1-2-4 m1-1-1-3-1,a1-1-3-1 m1-1-1-3-2,a1-1-3-2 m1-1-1-3-3,a1-1-3-3 m1-1-1-3-4,a1-1-3-4 m1-1-1-4-1,a1-1-4-1 m1-1-1-4-2,a1-1-4-2 .................................................... 6 - 1 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 197 Repeat this procedure for each function unit cabled to a DSX-1 via DS1/E1 cabling............................................Check off the appropriate box in the “Installation checklist” (p. II-5). T E P S ..................................................................................6 - 1 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 198 Facility Loopback testing allows the installer to verify the electrical cabling to the Alcatel- Lucent 1665 DMXtend NE. Follow the procedure below to perform a facility loopback test at the Alcatel-Lucent 1665 DMXtend shelf.
Page 199: Ds3/Ec1 Testing
DSX-3 ports called out in the procedure. If the Alcatel-Lucent 1665 DMXtend shelf is not fully populated, it may be necessary to move the circuit pack(s) from slot to slot in order to test all DS3/EC1 cabling.
Page 200 Set the DS3 test set to transmit and receive a framed Pseudo Random Bit Stream (PRBS) DS3 test signal CBIT or M13 (M13 is default). M13 should be used to test LNW39/LNW391/LNW84 (DS1/DS3/16/3)..................................................... 6 - 1 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 201 ..............................................................................................Connect a cable from the DS3 test set transmit connection to the IN jack of the DSX-3 associated with the first DS3 tributary of the Alcatel-Lucent 1665 DMXtend function unit slot to be tested............................................Connect a cable from the DS3 test set receive connection to the OUT jack of the DSX-3 associated with the first DS3 tributary of the Alcatel-Lucent 1665 DMXtend function unit slot to be tested.
Page 202 Select Delete legs of an Existing cross-connection............................................Select Next............................................main (OC-N). Click on the ............................................Double click on port 1 (OC-N)............................................Select Next..................................................... 6 - 1 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 203 DS3 tributaries of the function unit. Substitute the following address. Tributary Cross-connect @ DSX-3 address m1-1-2,d1-2 m1-1-3,d1-3 m1-1-4,d1-4 m1-1-5,d1-5 m1-1-6,d1-6 m1-1-7,d1-7 m1-1-8,d1-8 m1-1-9,d1-9 .................................................... 6 - 1 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 204 Facility loopback testing allows the installer to verify the electrical cabling to the Alcatel- Lucent 1665 DMXtend NE. Follow the procedure below to perform a facility loopback test at the Alcatel-Lucent 1665 DMXtend shelf. When the Alcatel-Lucent 1665 DMXtend...
Page 205 Once the test is complete, remove the loopback. Fault > Analysis > Loopback Select ............................................Choose the DS3 port to test and click Select............................................Release Loopback Type: Facility Apply Select and click .................................................... 6 - 2 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 206: Lnw74 And Lnw87 Testing
Controller and login to the shelf using the serial connection and the GUI options on ® WaveStar CIT............................................Identify the function groups that contain LNW74 or LNW87 circuit packs with cabling for testing..................................................... 6 - 2 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 207 Connect the RJ45 cable to the next jack on the RJ45 patch panel and repeat starting at Step until all connected jacks have been tested. T E P S ..................................................................................6 - 2 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 208: Oc-3 Low-Speed Testing
PTMs to ports that are fibered. LBOs are installed on the OLIU faceplate IN port............................................Beginning from the Top (G) side of the Alcatel-Lucent 1665 DMXtend shelf, locate the first function unit slot position that contains an LNW37 circuit pack............................................
Page 209 PC and the CIT/RS 232 port or OSI front LAN port of the System Controller and login ® to the shelf using the serial/LAN connection and the GUI options on WaveStar CIT............................................upd-sys Use the GUI window to send the command..................................................... 6 - 2 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 210 Step 2 Step 9 for OLIU ports 3 and 4............................................Repeat this entire procedure for each LNW37 PTM equipped in the Alcatel-Lucent 1665 DMXtend shelf............................................Replace all protective dust covers on the LNW37 PTM connectors (OLIU and LGX), that were removed to perform this procedure.
Page 211 PTMs to ports that are fibered. LBOs are installed on the OLIU faceplate IN port............................................Beginning from the Top (G) of the Alcatel-Lucent 1665 DMXtend shelf, locate the first function unit slot position that contains an LNW45 or LNW55 circuit pack............................................
Page 212 Result: The flashing FAULT LED should extinguish on the OC-3 OLIU. There should be no alarm indications on the Alcatel-Lucent 1665 DMXtend shelf............................................Remove PTM if necessary and the 15-dB LBO from OC-3 OLIU from (port 1) and plug it into the IN connector directly below it (port 2).
Page 213: Oc-12 Low-Speed Testing
T E P S ................................ OC-12 low-speed testing OC-12 low-speed LNW49 and LNW55 PTM testing procedure Perform the following steps for all Alcatel-Lucent 1665 DMXtend shelf function unit or growth slots containing OC-12 (LNW49 or LNW55) OLIU circuit packs... CAUTION Laser Safety When connecting fiber loops between the IN and OUT ports on optical circuit packs, always connect to the IN port first and then the OUT port.
Page 214 Stand-alone installation testing ..............................................................................................Beginning from the top (G) of the Alcatel-Lucent 1665 DMXtend shelf, locate the first function unit slot that contains an OC-12 OLIU circuit pack............................................Insert a 15-dB LC-type LBO into the top IN connector (port 1) of the OC-12 OLIU. See Appendix C, “Installing fiber connectors and...
Page 215 OLIU ports............................................Repeat this entire procedure for each LNW49 or LNW55 PTM equipped in the Alcatel- Lucent 1665 DMXtend shelf............................................Replace all protective dust covers on the LNW49 or LNW55 PTM OC-12 OLIU connectors (OLIU and LGX), that were removed to perform this procedure.
Page 216: Oc-48 Low-Speed Testing
LBOs are installed on the OLIU faceplate IN port............................................Beginning from the top (G) of the Alcatel-Lucent 1665 DMXtend shelf, locate the first function unit slot that contains an OC-48 OLIU circuit pack............................................
Page 217 Replace all protective dust covers on the OC-48 OLIU connectors, that were removed to perform this procedure............................................Repeat this entire procedure for each LNW31 OC-48 OLIU in the Alcatel-Lucent 1665 DMXtend shelf............................................Check off the appropriate box in the “Installation checklist”...
Page 218 “Safety”. Note: The LNW62, LNW55 and LNW402 circuit packs require the LNW141 or LNW84 be installed in the main slots to operate in a Alcatel-Lucent 1665 DMXtend shelf. Note: When reference is made to optical fiber loopback connections to IN and OUT on the OLIU, make the connections at the LGX equipment in order to verify correct installation and labeling of the fibers.
Page 219 Result: The flashing FAULT LED should extinguish on the OC-48 OLIU. There should be no alarm indications on the Alcatel-Lucent 1665 DMXtend shelf............................................Remove PTM if necessary and the 15-dB LBO from OC-48 OLIU from (port 1) and plug it into the IN connector directly below it (port 2).
Page 220: Oc-192 Low-Speed Testing
T E P S ................................ OC-192 low-speed testing OC-192 low-speed testing procedure Perform the following steps for all Alcatel-Lucent 1665 DMXtend shelf Function unit or Growth slots containing OC-192 (LNW603) OLIU. NOTICE Laser Safety When connecting fiber loops between the IN and OUT ports on optical circuit packs, always connect to the IN port first and then the OUT port.
Page 221 ............................................Replace all protective dust covers on the OC-192 OLIU connectors, that were removed to perform this procedure............................................Repeat this entire procedure for each OC-192 OLIU in the Alcatel-Lucent 1665 DMXtend shelf..................................................... 6 - 3 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1...
Page 222 Facility Loopback testing allows the installer to verify cabling to the OC-192 equipment. This test is only required if the Alcatel-Lucent 1665 DMXtend shelf is connected to OC- 192 equipment. If the shelf is NOT connected to OC-192 equipment, skip this section and continue to the next chapter.
Page 223 Verify loss of transmission at the patch panel. This should be evident by a SONET alarm and a loss of pattern alarm............................................Repeat this section for all OC-192 ports..................................................... 6 - 3 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 224: Led Test
................................ LED test Description This test verifies proper operation of all LEDs on the Alcatel-Lucent 1665 DMXtend circuit packs. Operation of all the LEDs is necessary to assist in trouble isolation. Note: If there are any LED failures, determine if the problem is with the circuit pack or shelf and replace the faulty unit.
Page 225: Office Alarm Test
“Office alarm connections” (p. 6-42) lists the office alarms connections. It is a requirement that alarms on the Alcatel-Lucent 1665 DMXtend do not affect and • are not affected by other equipment via office alarm connections. During this test, the alarm state of other equipment connected to the same office alarms as the Alcatel- Lucent 1665 DMXtend should be examined after creating or clearing every alarm.
Page 226: Office Alarm Connections
Steps ............................................Connect the office alarm cable to J13 (ALM) on the backplane of the Alcatel-Lucent 1665 DMXtend shelf. If the shelf to be tested is part of a multiple shelf bay arrangement, the office alarm cable connects to shelf 1.
Page 227 LNW39/LNW391 or LNW112 circuit pack in function unit A-1 and/or A-2 slot(s) to the first STS-1 of the Main OLIUs............................................Finish Click to issue the command............................................Use the to view the cross-connects..................................................... 6 - 4 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 228 Unseat the second circuit pack from the same function group pair as the circuit pack removed in Step Result: Activated office alarms: CR visual, CR audible..................................................... 6 - 4 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 229: Automatic Protection Switching And Alarm Test
A properly grounded wrist strap must always be worn while handling circuit packs. • This test is performed with the Alcatel-Lucent 1665 DMXtend shelf optically looped • back on itself (that is, with the IN of the OLIU M1 looped to the OUT of the OLIU M1, and the IN of the OLIU M2 looped to the OUT of the OLIU M2).
Page 230 View > Cross-Connections Click on the ............................................Shelf Select ............................................Select Click to issue the command. Result: The cross-connects entered previously should still be in place..................................................... 6 - 4 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 231 OLIU that was originally active............................................Check off the appropriate box in the “Installation checklist” (p. II-5). T E P S ..................................................................................6 - 4 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 232 The FAULT LED on the second circuit pack will light for several seconds then extinguish. On the SYSCTL, the MN alarm extinguishes............................................Repeat this procedure for each equipped function group..................................................... 6 - 4 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 233: Manual Switching Tests
............................................Fault > Protection Switch > Path Protection. Click on the ............................................Path m1-1-1 Double Click on a path; e.g., ............................................Active Path Observe the displayed..................................................... 6 - 4 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 234 This test will initiate switching commands from the CIT and verify proper switching and LED indications. Note: This procedure should be performed on each function unit and/or growth slot pair..................................................... 6 - 5 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 235 Double Click on a path; e.g., ............................................Switch Type Manual select ............................................Apply Click to issue the command............................................Click ............................................View > Equipment Click on the .................................................... 6 - 5 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 236: External Timing Verification
External timing verification Description This test should be performed if the Alcatel-Lucent 1665 DMXtend shelf is going to be externally timed. The shelf timing cable must be installed and connected between the Alcatel-Lucent 1665 DMXtend shelf and the office timing source (BITS clock) and the timing source must be active.
Page 237 • Note: If a reference does not indicate is, that input is not receiving a proper timing reference. Verify: – Cabling between the timing source and the Alcatel-Lucent 1665 DMXtend shelf – Correct line coding .................................................... 6 - 5 3 Alcatel-Lucent 1665 DMXtend R10.0...
Page 238: Alcatel-Lucent 1665 Dmxtend Shelf Backplane
.................................................... – Correct frame format ............................................At the rear of the shelf [see Figure 6-1, “Alcatel-Lucent 1665 DMXtend shelf backplane” 6-54)], disconnect the input timing cable from the connector associated with the active reference. Result: The MN LED lights solid on the SYSCTL and the FAULT LED flashes on the Main OLIU circuit pack associated with that reference (SYNC1 is associated with M1 and SYNC2 is associated with M2).
Page 239: Miscellaneous (Environmental) Discrete Telemetry Test
Steps ............................................Determine which environmental inputs are to be monitored via the Alcatel-Lucent 1665 DMXtend shelf............................................Verify that the miscellaneous discrete cable is connected to the J20 MISC connector on the shelf.
Page 240 Step 10 for each environmental input being used............................................Check off the appropriate box in the “Installation checklist” (p. II-5). T E P S ..................................................................................6 - 5 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 241: Miscellaneous (Environmental) Discrete Functions
High Temp, High Water, Fire, etc.) Env. Input #19 Env. Output #1 Env. Output #2 Generator, Env. Output #3 Pump, etc. Env. Output #4 Output Common .................................................... 6 - 5 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 242: Miscellaneous (Environmental) Discrete Telemetry Connections
Env. Output - #1 BK-BL TLMO2 Env. Output - #2 O-BK TLMO3 Env. Output - #3 BK-O TLMO4 Env. Output - #4 G-BK TLMOC Output Common .................................................... 6 - 5 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 243: Modem Connection Test
Stand-alone installation testing .................................................... Modem connection test Description This test will verify proper modem connection to the Alcatel-Lucent 1665 DMXtend shelf. This test should only be performed if a modem is required. Steps ............................................Verify the generic parameters of the modem are set to the following:...
Page 244 A message indicating that the command completed will be displayed............................................Disconnect the HyperTerminal session............................................Check off the appropriate box in the “Installation checklist” (p. II-5). T E P S ..................................................................................6 - 6 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 245: Final Operations
Stand-alone installation testing .................................................... Final operations Description The following procedure ensures that all test signals and cross-connects have been removed and the Alcatel-Lucent 1665 DMXtend shelf is alarm free and ready for network connection procedures. Steps ............................................Use the to View and Delete any cross-connects that were entered.
Page 246 Stand-alone installation testing ......................................................................................................6 - 6 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 247: Part Iii: Network Turn-Up And Testing
Introduction Part III covers fiber connections between nodes in a ring and used to verify WDMX connectivity between Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) nodes. It is not intended to replace acceptance test procedures. If problems are encountered, see Alcatel-Lucent 1665 Data Multiplexer Extend (DMXtend) User Operations Guide, 365-372-325 for detailed troubleshooting procedures.
Page 248 2 or 3 LC-type Optical Fiber Two optical fiber jumpers with LC type connectors are Jumper ITE-7169 required to optically loop the Alcatel-Lucent 1665 (108918269) DMXtend shelf for test purposes. In addition, for shelves containing optical circuit packs in any of the function unit slots, a single optical fiber jumper is required for testing of the individual ports.
Page 249 Luminex Cloth R-6033 5.5” x 5.5” ® PC and cable requirements for WaveStar ® This section lists the required equipment needed to run the WaveStar CIT software with the Alcatel-Lucent 1665 DMXtend. Quantity Description Comments Personal Computer PC minimum requirements.
Page 250 “Turn up and test the LNW705 muxponder” See Note 1 (p. 8-6) “Removing provisioning and equipage from the See Note 1 LNW785” (p. 8-16) Notes: 1. Only required if equipped..................................................... II I- 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 251: Connecting Adjacent Network Elements
This procedure is used to make fiber connections between nodes in a ring. It is not intended to replace acceptance test procedures. If problems are encountered, see Alcatel- Lucent 1665 Data Multiplexer Extend (DMXtend) User Operations Guide, 365-372-325 for detailed troubleshooting procedures.
Page 252: Connecting Adjacent Network Elements
DS3 cabling. A T-BERD 2209 or equivalent is recommended. Personal Computer (PC) CIT Interface Cable 8-ft. long RJ45 to 9-pin D-sub serial cable (Comcode 848748869). Optical Power Meter ..................................7 - 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 253: Fiber Installation
Fiber installation Description This section is used to verify proper fiber connections between Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) nodes. Prerequisite The following is a list of items to verify before beginning tests in this section.
Page 254 Verify that the office alarm cable to J13 (ALM) on the backplane of the Alcatel-Lucent 1665 DMXtend shelf is disconnected. If the shelf to be tested is part of a multiple shelf bay arrangement, the office alarm cable connects to shelf 1.
Page 255 OLIU circuit packs to avoid equipment damage. Note: The Alcatel-Lucent 1665 DMXtend OLIUs require single-mode lightguide cable. Single-mode optical fibers connecting this shelf with the far-end shelf should not be connected to the OLIU until at least 45 seconds after an optical loopback is removed.
Page 256: Attenuation Table
(OC-3, OC-12 or OC-48) using 0x1 protection, the Function Group slot (D, or G) 1 will connect to Main 2 on whatever shelf the Alcatel-Lucent 1665 DMXtend is being connected to. The Function Group slot (D, or G) 2 will connect to Main 1.
Page 257 Select the proper LBO based on the value required and the comcode as listed below. Code Comcode Loss (dB) ABLCS-05.0 108279381 ABLCS-10.0 108279431 ABLCS-15.0 108279480 ABLCS-20.0 108279530 ..............................Clean LC LBOs and install LBO assemblies in the OLIU IN connector..................................7 - 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 258 At the other end, verify that the associated FAULT LED is flashing, indicating a loss of signal. Reconnect the fiber and repeat the process for the other direction of transmission..............................In order to enable communications with the adjacent Alcatel-Lucent 1665 DMXtend nodes, ..............................
Page 259 ..............................Click to issue the command..............................In order to verify proper communications with the adjacent Alcatel-Lucent 1665 DMXtend nodes, execute the following command from the Administration > OSI-Neighbor-Map Result: The TIDs and NSAPs of adjacent nodes will be displayed along with the OLIU and port they are connected to.
Page 260: Optical Transmission Test (Oc-192, Oc-48, Oc-12, Oc-3)
Performance > View PM/Statistics Reports > OCn Line ..............................CP main-1 Double-click ..............................Port 1 (OC3) Select ..............................Time Period 1 Day. select ..............................Monitored Date, Current Date. select ..................................7 - 1 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 261: Automatic Protection Switching Test
III-4). T E P S ................................ Automatic protection switching test Description This section provides the procedures for verifying the Alcatel-Lucent 1665 DMXtend shelf automatic and manual protection switching. Note the following: These tests do NOT simulate circuit pack failures. •...
Page 262 OLIU that was originally active..............................Check off the appropriate box in the “Installation checklist” (p. III-4). T E P S ................................................................7 - 1 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 263: Manual Switching Tests
..............................Check off the appropriate box in the “Installation checklist” (p. III-4). T E P S ................................................................7 - 1 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 264 Select Click ..............................Note which function unit or growth slot circuit pack is the active circuit pack..............................Switch Type: Manual (Normal) In the pull-down, select ..................................7 - 1 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 265: Final Operations
T E P S ................................ Final operations Description The following procedure ensures that all test signals and cross-connects have been removed and the Alcatel-Lucent 1665 DMXtend shelf is alarm free and ready for network connection procedures. Steps ..............................View > Cross-Connections...
Page 266 ..............................Next Select ..............................Finish Select ..............................Select to the execution warning message..............................Repeat Step 1 through Step 14 to verify no further cross-connects exist..................................7 - 1 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 267 ................................................................ Verify that no alarm LEDs are lit and no FAULT LED is lit on any circuit pack. If any alarm is present, see Alcatel-Lucent 1665 Data Multiplexer Extend (DMXtend) User Operations Guide, 365-372-325. T E P S ................................
Page 268 Connecting adjacent network elements ....................................................................7 - 1 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 269: Wdmx Setup And Testing: Integration Procedures
Overview Purpose This chapter is used to verify WDMX connectivity between Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) nodes. The chapter includes the LNW785 8 channel Optical Multiplexer Demultiplexer (OMD) circuit pack. It is not intended to replace acceptance test procedures.
Page 270: Wdmx Setup And Testing: Integration Procedures
Safety instructions Note: All precautions should be observed when handling fiber. WARNING Laser hazard Unterminated optical connectors may emit laser radiation. Do not view beam with optical instruments..................................8 - 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 271 When connecting fiber loops between the IN and OUT ports on optical circuit packs, always connect to the IN port first and then the OUT port. This will prevent any optical radiation from being present at the fiber end..................................8 - 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 272: Turn-Up And Test The Lnw785 8-Channel Omd
..............................Determine and document the test signal frequency..............................Install the LNW785 into the Alcatel-Lucent 1665 DMXtend shelf by opening both faceplate latches and seating in the slot while closing the latches. Note: The LNW785 can be installed in any Function/Growth slot. When the shelf is to be configured as an add/drop, it is recommended that the Growth slots are not used because the passthrough fibers would have to route over the SYSCTL.
Page 273 ..............................Perform end-to-end testing. Follow the end to end testing procedures determined by the input test signal. If the test signal is the Alcatel-Lucent 1665 DMXtend as part of a ring, proceed to Chapter 8, “WDMX setup and testing: integration procedures”...
Page 274: Turn Up And Test The Lnw705 Muxponder
Steps This procedure provides the steps needed to equip and test an Alcatel-Lucent 1665 DMXtend with one LNW705 in G2. The steps include installing and equipping the LNW705 with the 10G and low speed PTMs, along with all the necessary provisioning.
Page 275 WDMX setup and testing: integration procedures ................................................................ ® Login to the Alcatel-Lucent 1665 DMXtend using the WaveStar CIT..............................Provision the PTM/OTU-2 Select Configuration > Equipment from the System View ..............................Click the “+” next to XM10G/8 circuit pack to expand the list.
Page 276 Disconnect test set(s) and fiber jumper from ports..............................Remove PTM from LNW705 if necessary and clear any associated alarms by selecting Configuration > Update System> Update Inventory..................................8 - 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 277: Integrating The Lnw705 Into The Lnw785
Steps ..............................Install the LNW785 into the Alcatel-Lucent 1665 DMXtend shelf by opening both faceplate latches and seating in the slot while closing the latches. Note: The LNW785 can be installed in any Function/Growth slot. When the shelf is to be configured as an add/drop, it is recommended that the Growth slots are not used because the passthrough fibers would have to route over the SYSCTL.
Page 278 LBO/Attenuator. Note: Test duration may be determined by engineering specification or by the end customer..............................Disconnect test set(s) and fiber jumper from ports..................................8 - 1 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 279: Removing Provisioning And Equipage From The Lnw705 And Lnw785
Description This section provides procedures on how to properly remove provisioning from the Alcatel-Lucent 1665 DMXtend shelf once testing is completed and the equipment/ports are no longer needed. Locate the procedure below to remove the equipment and return the Alcatel-Lucent 1665 DMXtend back to the original status.
Page 280 End the OCH cross-connection Wizard session by clicking Close. T E P S ................................ Delete LNW785 circuit pack ..............................Remove the LNW785 circuit pack from the Alcatel-Lucent 1665 DMXtend shelf..............................Update the Alcatel-Lucent 1665 DMXtend inventory. Select Configuration > Update System > Update Inventory ..............................
Page 281: Channel/Port Assignments
STNA then Apply then Close. T E P S ................................ Delete LNW705 circuit pack ..............................Remove the LNW705 circuit pack from the Alcatel-Lucent 1665 DMXtend shelf..............................Update the Alcatel-Lucent 1665 DMXtend inventory Select Configuration > Update System > Update Inventory ..............................
Page 282: Connecting The Ring (Mains) To The Wdmx
8-4). In some instances, only one direction may be added to the WDMX circuit pack. Main 1 is always referred to as the West direction, while Main 2 is the East ..................................8 - 1 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 283 Only PTMs X10G52C5 through X10G59C5 can be used in the LNW141, . Only X10G53C5, X10G56C5, and X10G58C5 can be used in the LNW603..............................® Login to the Alcatel-Lucent 1665 DMXtend using the WaveStar CIT..............................Provision the PTM/OTU-2 Select Configuration > Equipment from the System View ..............................
Page 284: Removing Provisioning And Equipage From The Lnw785
Description This section provides procedures on how to properly remove provisioning from the Alcatel-Lucent 1665 DMXtend shelf once testing is completed and the equipment/ports are no longer needed. Locate the procedure below to remove the equipment and return the Alcatel-Lucent 1665 DMXtend back to the original status.
Page 285 WDMX setup and testing: integration procedures ..................................Deleting the OCH cross-connection ..............................® Login to the Alcatel-Lucent 1665 DMXtend using the WaveStar CIT..............................Retrieve OCH Cross-connections. Select View > OCH Cross-connections from the System View ..............................Click the “+” next to OMD5/8 circuit pack to expand the list.
Page 286 III-4). T E P S ................................ Delete LNW785 circuit pack ..............................Remove the LNW785 circuit pack from the Alcatel-Lucent 1665 DMXtend shelf..............................Update the Alcatel-Lucent 1665 DMXtend inventory Select Configuration > Update System > Update Inventory ..............................Click Yes to acknowledge the request.
Page 287: Channel/Port Assignments
-8.0 to -30.5 OC-48 PTM LNW41/55/62 LR-1 Optics -9.0 to -27.0 (pluggable LNW41/55/62 LR-2 Optics -9.0 to -28.0 transmission module) optics LNW41/55/62 SR-1 Optics -3.0 to -18.0 ..................................8 - 1 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 288 LNW49/55 OC-12 LR-1 +2.0 to -5.0 -5.0 to -15 -15 to -28.0 Received power Optics Circuit pack (dBM) (dB) OC-3 (high LNW40 -8.0 to -28.0 speed) ..................................8 - 2 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 289: Part Iv: Miscellaneous Detailed Installation Procedure And Reference Material
Overview Purpose This section provides supplementary information that is useful when installing the Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) system and using this Installation Manual. This section is comprised of the following appendixes: Appendix A, “Fiber cleaning”...
Page 290 Miscellaneous detailed installation procedure and reference material ......................................................................................................IV- 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 291: Fiber Cleaning
Overview Purpose This appendix describes the Alcatel-Lucent recommended method for the cleaning and inspection of optical connectors using specific tools and materials that have been proven to be effective in the assembly and testing of optical transmission equipment. It is critical that connector faces are clean and free from particular contamination to assure proper performance and reliability of lightwave systems.
Page 292: Fiber Cleaning
Related information A course on connector cleaning and the connector inspection process is now offered through Alcatel-Lucent University, Course Code: LMC200H “Understanding Fiber Optic Cleaning, Inspection and Testing.” To learn more about this course, consult your local Alcatel-Lucent Account Representative.
Page 293: Safety Instructions
“wet” solvent such as high purity alcohol to the connector endface to dissolve/remove any organic particulate or oily films, followed by a “dry” double clean wipe using the CLETOP cleaning cassette..................................................... A- 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 294: Cleaning The Ferrule Endface
Step 7. Otherwise, hold the CLETOP cassette cleaner in the palm of your hand with the cassette shutter door facing up. See Figure A-2, “CLETOP cleaner” (p. A-5)..................................................... A- 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 295 Release the cassette lever allowing the shutter door to close to its initial position. Continue with Step ............................................Wrap a Luminex cleaning cloth around the ferrule and rotate the connector housing, cleaning the outside periphery of ferrule..................................................... A- 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 296 The visual area of the ferrule endface (ferrule and fiber) as observed by the inspection system/scope should be free of any contaminates. See Figure A-3, “Acceptability criteria for fiber cleaning” (p. A-7)..................................................... A- 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 297: Acceptability Criteria For Fiber Cleaning
(swab) of the same inside diameter as the cap (either 2.5 or 1.25 mm) and rotating the stick 360 degrees three (3) times. Following this procedure, carefully place the .................................................... A- 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 298 Verify that the fiber ferrule is clean. Repeat Step 1 through Step 3 if the fiber does not meet the requirements specified in “Connector inspection” (p. A-6). T E P S ..................................................................................A- 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 299: Cleaning Pluggable Optics Module
.................................................... Cleaning pluggable optics module Purpose This task describes the Alcatel-Lucent recommended method for cleaning pluggable optics modules using specific tools and materials that have been proven to be effective in the assembly and testing of optical transmission equipment. Note: Pluggable optics modules are shipped with a water-tight process plug installed into the optical ports to maintain cleanliness during storage and/or transportation.
Page 300 ............................................If required, reinstall the process plug into the optical ports to maintain cleanliness. T E P S ..................................................................................A- 1 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 301: Pluggable Transmission Module (Ptm) Installation
Overview Purpose This chapter describes the how to insert a Pluggable Transmission Module (PTM) into a Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) circuit pack. These PTMs were once referred to as Small Form Programmable (SFP)s. Contents This chapter contains the following:...
Page 302: Ptm Modules
Pluggable Transmission Module (PTM) installation .................................................... PTM modules Alcatel-Lucent approved Class 1 PTM transceivers The following table lists all the current approved PTM modules to be used with Alcatel- Lucent 1665 DMXtend. Table B-1 Alcatel-Lucent approved PTMs Optical module Compatible circuit...
Page 303 OC48 PTM TRCVR 1310 LNW41, LNW55, 109493528 Long Reach LR1 LNW62, LNW84, LNW402, LNW705 OM2.5G 1.5LR2 OC48LR2-I1 OC48 PTM TRCVR 1550 LNW41, LNW55, 109504431 Long Reach LR1 LNW62, LNW84, LNW402, LNW705 .................................................... B- 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 304 OM2.5G 1.5LR2 S2D45C6 OC48/STM16/OTU1 LNW41, LNW55, 109610600 DWDM LNW62, LNW84, 194.5 THz/1541.349 nm LNW402 OM2.5G 1.5LR2 S2D47C6 OC48/STM16/OTU1 LNW41, LNW55, 109610626 DWDM LNW62, LNW84, 194.7 THz/1539.766 nm LNW402 .................................................... B- 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 305 DWDM, Long Reach, 1556.555 nm OM10G DWDMLR X10G27C5 OC-192/STM-64/OTU2 LNW141 (DW100U-2AxC(F)) 109615062 DWDM, Long Reach, 1555.747 nm OM10G DWDMLR X10G28C5 OC-192/STM-64/OTU2 LNW141 (DW100U-2AxC(F)) 109615070 DWDM, Long Reach, 1554.940 nm .................................................... B- 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 306 DWDM, Long Reach, 1534.250 nm OM10G DWDMLR X10G55C5 OC-192/STM-64/OTU2 LNW141 (DW100U-2AxC(F)) 109615344 DWDM, Long Reach, 1533.465 nm OM10G DWDMLR X10G56C5 OC-192/STM-64/OTU2 LNW141, LNW603 (DW100U-2AxC(F)) 109615351 DWDM, Long Reach, 1532.681 nm .................................................... B- 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 307 GE-1X2XFC-LX-I1 GbE long-reach, Single- LNW63, LNW64, 1000BASE-LX// Mode PTM, supports LNW73, LNW73C, 109568782 100/200-SM-LL-LI Ethernet and Fibre- LNW87, LNW170, Channel traffic, LC-type LNW705, LNW910 connectors, OSP hardened (GbE/FC/2FC-850) .................................................... B- 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 308: Install Pluggable Modules
Hold the optical connector/latch-end of the module in your left hand with the gold fingers facing you. The module should be positioned in manner similar to Figure B-1, “Pluggable optics module” (p. B-9)..................................................... B- 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 309: Pluggable Optics Module
Do not remove the dust plug unless you are ready to connect fibers or if you need to clean the module............................................Referring to Figure B-2, “Module types” (p. B-10), determine the type of latching mechanism on the pluggable optical module purchased..................................................... B- 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 310: Module Types
Pluggable Transmission Module (PTM) installation .................................................... Figure B-2 Module types Gold Fingers Port Gold Fingers Port Gold Fingers Port MA-DMX-445 Gold Fingers Port Gold Fingers Port Gold Fingers Port MA-DMX-439 .................................................... B- 1 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 311 Proceed to Step 9 Type 3 Continue with Step 6 Type 4 Proceed to Step 8 Before inserting the module, the latch must be in the closed position..................................................... B- 1 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 312 Rotate the optical module 45 degrees counter-clockwise. The dust plug is facing you and the gold fingers are pointed to the right. (Do not insert optical module.) .................................................... B- 1 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 313 Each optical module has unique internal data for warranty purposes. If this data for any reason is not unique, both optical modules with the duplicated information will be declared failed. See the Alcatel- Lucent 1665 Data Multiplexer Extend (DMXtend) User Operations Guide, 365-372- 325.....................................................
Page 314 T E P S ................................ Cable routing for electrical PTMs This procedure describes how to route electrical PTMs comcode 109565549 cables in a Alcatel-Lucent 1665 DMXtend shelf............................................Insert the PTM module in ports 1 through 4 of the LNW170 card............................................
Page 315: Electrical Ptm Routing
Pluggable Transmission Module (PTM) installation .................................................... Figure B-5 Electrical PTM routing T E P S ..................................................................................B- 1 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 316 Pluggable Transmission Module (PTM) installation ......................................................................................................B- 1 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 317: C Installing Fiber Connectors And Lbos
Overview Purpose This appendix provides procedures for installing and removing Line Build Out units (LBOs) and fiber connectors onto input and output ports found on the Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) optical circuit packs. Contents This chapter provides information on the following topics:...
Page 318: Lc-Type Connector Ports On Circuit Pack
LBOs are fixed-value optical attenuators that mate into mounting blocks and provide a specific connector interface (LC, ST, FC or SC-type) for external fiber connections. The Alcatel-Lucent 1665 DMXtend optical circuit packs are equipped with LC-type connector ports designed for use with LC-type LBOs and fiber connectors. Dust caps should be applied on all LBOs when not installed in connector ports.
Page 319: Lc-Type Lbo
Removal of LC-type LBO from LC block The LC-type LBOs are removed from the LC-type connector port by depressing the tab to release the LBO and then pulling straight out..................................................... C - 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 320: Circuit Pack Attenuation Table
-8.0 to -28.0 speed) LNW601 0.0 to -15.0 -15.0 to -34.0 OC-12 (high LNW38 -8.0 to -28.0 speed) LNW51 -8.0 to -30.5 Low-Speed LNW31 0.0 to -18.0 Optics (OC-48) .................................................... C - 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 321: Ptm Attenuation Table
LNW402, LNW705 -10.0 to -15.0 -15.0 to -27.0 OC48LR2-I1 LNW41, LNW55, +3.0 to -5.0 LNW62, LNW84, -5.0 to -10.0 LNW402, LNW705 -10.0 to -15.0 -15.0 to -27.0 .................................................... C - 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 322 LNW62, LNW84, -5.0 to -10.0 LNW202, LNW402, LNW705 -10.0 to -15.0 -15.0 to -27.0 S2G7CxxLI LNW41, LNW55, 0 to 8.0 LNW62, LNW84, -9.0 to -24.0 LNW202, LNW402 .................................................... C - 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 323: Fiber Connections
108279530 Fiber connections General Alcatel-Lucent 1665 DMXtend uses AllWave ADVANTAGE™ Lightguide Jumpers, part of Alcatel-Lucent’s AllWave ADVANTAGE™ Optical Connectivity Solution (OCS). These jumpers contain a boot angled at 40 degrees, allowing the jumpers to dress appropriately into the fiber tray. The angled boot eliminates projection outside the front of the shelf assembly.
Page 324: Lc-Type Fiber Connector
The LC-type fiber connector is removed from a connector port by depressing the snap- action lever to disengage the fiber connector. Figure C-6 LC-type fiber connection ALIGNMENT SLOT DEPRESS LEVER TO RELEASE THE SNAP-ACTION TAB .................................................... C - 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 325: Backplane Pin Replacement
Overview Purpose This appendix provides information and the procedures used when a connector and/or pin on the Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend) backplane has been bent or broken. Contents This appendix provides information on the following topics:...
Page 326: Pin And Connector Background
Pins are identified by a column and row position on the backplane. D-Subminiature connectors are identified by their designation and J-number. All the METRAL™ pins used on the Alcatel-Lucent 1665 DMXtend shelves have the same tail length of 4.30 mm (0.169 in.).
Page 327: Repair Kits And Tools
All the METRAL™ pins used on the Alcatel- Lucent 1665 DMXtend shelves have the same tail length of 4.30 mm (0.169 in.). Additional replacement signal pins may be ordered in packages of 100 by the part number shown in Table D-2, “Metral™...
Page 328: Simple Repair Methods
If the visual examination suggests that the connector pins are loose or are damaged beyond repair, replace the connector pin..................................................... D- 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 329: Replacement Methods
D-subminiature pins The D-Subminiature connectors on the Alcatel-Lucent 1665 DMXtend backplane are all of the receptacle type. These connectors are designated as jacks and not as plugs. The individual connector terminals are protected somewhat by the molded plastic insert inside the connector shell.
Page 330 Note: Any press-fit connector pin may be removed and replaced one time in the Alcatel-Lucent 1665 DMXtend backplane. A second removal and replacement in the same plated-through hole may not meet the long-term reliability objectives. If a replacement is needed for a previously replaced connector pin, contact your next level of support before proceeding.
Page 331 RJ45 jacks If it becomes necessary to replace a RJ45 connector, contact your next level of support for the replacement procedure..................................................... D- 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 332 Backplane pin replacement ......................................................................................................D- 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 333: Fiber Labeling
Fiber description Fibers There are three different types of single-mode fiber used with the Alcatel-Lucent 1665 Data Multiplexer Extend (Alcatel-Lucent 1665 DMXtend), simplex blue fiber, simplex yellow fiber, and the customer's fiber, and two types of multi-mode fiber used with the Alcatel-Lucent 1665 DMXtend, multi-mode simplex gray fiber and the customer's multi- mode fiber.
Page 334 50 feet), as well as custom lengths. Outside fiber Outside fiber is the fiber connecting the Customer equipment to the Alcatel-Lucent 1665 DMXtend. Depending on the customers specifications, these fibers may be any combination of SC, FC, or ST connectors. The length of these fibers depends on the system interface setup.
Page 335: Fiber Labels
Labeling the fibers To apply the labels to the connectors, use the following procedure............................................Remove the appropriate label from the backing sheet or the label maker..................................................... E - 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 336 Do not apply the label diagonally to the boot. The label must wrap directly on top of itself for the adhesive to work. T E P S ..................................................................................E - 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 337: Glossary
Access Resource Manager AS&C Alarm, Status, and Control ASCII American Standard Code for Information Interchange ASN.1 Abstract Syntax Notation 1 ASNE Alarm Server Network Element Asynchronous Transfer Mode .................................................... G L- 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 338 International Telephone and Telegraph Consultative Committee Controlled Environment Vault CD-ROM Compact Disk, Read-Only Memory CDTU Channel and Drop Test Unit Craft Interface Terminal Carrier Line Failure Status .................................................... GL - 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 339 Channel Service Unit CS&O Customer Support and Operations Customer Release Notes Coding Violation CVFE Coding Violation Far End .................................................... Data Communications Channel Data Communications Equipment DEMUX Demultiplexer .................................................... G L- 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 340 Data Terminating Equipment .................................................... EC-1 Electrical Carrier Level 1 Equipment Catalog Item EEPROM Electrically-Erasable Programmable Read-Only Memory Electronic Industries Association Electromagnetic Compatibility Electromagnetic Interference EOOF Excessive Out of Frame .................................................... GL - 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 341 Far End Block Error FE ID Far End Identification FEPROM Flash EPROM FERF Far End Receive Failure FE SEL Far End Select Failures in 10 hours of operation..................................................... G L- 5 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 342 Global Technical Support Information Platform Graphical User Interface .................................................... HECI Humans Equipment Catalog Item .................................................... Internal Clock Identifier International Electrotechnology Commission Infant Mortality Factor Incoming Status Input/Output Internet Protocol Intermediate Reach .................................................... GL - 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 343 LAPD Link Access Procedure "D" Line Build Out Local Communications Network Local Exchange Carrier Light-Emitting Diode Loss of Frame Loss of Pointer Loss of Signal Long Reach .................................................... G L- 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 344 Mean Time Between Failures MTBMA Mean Time Between Maintenance Activities Mult Multipling Multiplex MXBIU Multiplexer and Backplane Interface Unit .................................................... Near End Network Element NE ACTY Near-End Activity .................................................... GL - 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 345 Optical Carrier Level 3 Signal (155 Mb/s) OC-12 Optical Carrier Level 12 Signal (622 Mb/s) OC-48 Optical Carrier Level 48 Signal OLIU Optical Line Interface Unit Out of Frame .................................................... G L- 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 346 Personal Computer Power Conversion Unit Program Identification PINFET Positive Intrinsic Negative Field Effect Transistor Pointer Justification Count Phase-Locked Loop Performance Monitoring Power Minor Alarm Path Overhead .................................................... GL - 1 0 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 347 Random Access Memory Reliability Prediction Procedure (described in Telcordia Technologies TR-NWT-00032) Remote Terminal Return to Zero .................................................... Service Affecting SCADA Supervisory Control and Data Acquisition Signal Degrade .................................................... G L- 1 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 348 Synchronous Transport Signal Synchronous Transfer Mode STS-1 SPE STS-1 Synchronous Payload Envelope STS-3c Synchronous Transport Level 3 Concatenated Signal STS-12c Synchronous Transport Level 12 Concatenated Signal .................................................... GL - 1 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 349 Time Division Multiplexing Target Identifier Transaction Language 1 Timing Looped Back Task Oriented Practice Telcordia Technologies Technical Requirement Time Slot Assignment Time Slot Interchange Technical Support Organization .................................................... G L- 1 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 350 Violation Monitor and Removal VoIP Voice over Internet Protocol VONU Virtual Optical Network Unit Virtual Private Network Virtual Tributary VT1.5 Virtual Tributary 1.5 (1.728 Mb/s) VT-G Virtual Tributary Group .................................................... GL - 1 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 351: Terms And Definitions
1xN protection switching pertains to circuit pack protection that provides a redundant signal path through the Alcatel-Lucent 1665 DMXtend (it does not cover protection switching of an optical facility; se "1+1"). In 1xN switching, a group of N service circuit packs share a single spare protection circuit pack.
Page 352 CC - Clear Channel A provisionable mode for the DS3 output that causes parity violations not to be monitored or corrected before the DS3 signal is encoded..................................................... GL - 1 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 353 Lucent’s first generation SONET multiplexers that multiplex DS1, DS3, or EC-1 inputs into EC-1, OC-1, OC-3, or OC-12 outputs. Default Provisioning The parameter values that are preprogrammed as shipped from the factory..................................................... G L- 1 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 354 (accepts transmitted data) or both. Dual Homing A network topology in which two Alcatel-Lucent 1665 DMXtends serve as hosts supporting up to 8 OC-3 rings or 4 OC-12 rings. Each OC-3 and OC-12 ring is interconnected between the two separate hosts.
Page 355 An operating condition of a clock in which its local oscillator is not locked to an internal synchronization reference and is using no storage techniques to sustain its accuracy. FT-2000 Lucent’s SONET OC-48 Lightwave System..................................................... G L- 1 9 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 356 .................................................... Function Unit Refers to any one of a number of different circuit packs that can reside in the A/B, D, or G function unit slots on the Alcatel-Lucent 1665 DMXtend..................................................... GNE - Gateway Network Element A network element that has an active X.25 link. Can also be a DSNE.
Page 357 See Intermediate Reach..................................................... Main The two slots (M-1 and M-2) on the Alcatel-Lucent 1665 DMXtend shelf in which the OC-3 or OC- 12 main OLIU circuit packs are installed. Midspan Meet The capability to interface between two lightwave terminals of different vendors. This applies to high-speed optical interfaces.
Page 358 OC, OC-n - Optical Carrier The optical signal that results from an optical inversion of an STS signal; that is, OC-1 from STS-1 and OC-n from STS-n..................................................... GL - 2 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 359 PM - Performance Monitoring Measures the quality of service and identifies degrading or marginally operating systems (before an alarm would be generated)..................................................... G L- 2 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 360 SONET APS channel (K1 and K2 bytes in the SONET line overhead). On a Alcatel-Lucent 1665 DMXtend, a protection line is a pair of fibers that terminate an OLIU circuit pack in the Main-2, D-2, or G-2 slots. See Service Line.
Page 361 DCC. Service Line On a Alcatel-Lucent 1665 DMXtend system, a service (or "working") line is a pair of fibers (one transmit and one receive) that terminate on an OLIU circuit pack in the Main-1, D-1, or G-1 slots.
Page 362 In performance monitoring, the count of seconds in which a signal is declared failed or, in which, 10 consecutively severely errored seconds (SES) occurred, until the time when 10 consecutive non- SES occur..................................................... GL - 2 6 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 363 Zero Code Suppression A technique used to reduce the number of consecutive zeros in a line-codes signal (B3ZS for DS3 signals and B8ZS for DS1 signals)..................................................... G L- 2 7 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 364 Terms and definitions ......................................................................................................GL - 2 8 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 365 ................optical fiber 3-59 3-61 cross-connects 3-62 3-63 battery distribution fuse board VT1.5 (BDFB) 2-13 2-14 2-15 power 2-14 bay frame ground power cable .................................................... I N - 1 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 366 6-34 OC-3 Extended superframe (ESF) 6-52 laser radiaition 3-63 optical fiber cables 3-61 external buffer relay 3-50 laser radiation 3-58 3-59 3-61 3-62 3-63 6-46 OC-48 .................................................... I N - 2 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 367 3-54 III-2 RJ-45 connector pinouts timing external sync 3-49 ................verification 6-52 safety tools instructions CLETOP cleaning cassette laser 6-24 6-27 II-3 III-3 6-29 6-32 6-34 .................................................... I N - 3 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...
Page 368 Index ......................................................................................................I N - 4 Alcatel-Lucent 1665 DMXtend R10.0 365-372-327R10.0 Issue 1 January 2013...

Alcatel-Lucent 1665 Installation Manual

About this Document

Safety

Safety

Part I: Physical and Power Installation

Physical Installation

Physical Installation

Cable and Fiber Installation

3 Cable and Fiber Installation

Circuit Pack Installation

Circuit Pack Installation

Part II: Stand-Alone Installation Tests

Stand-Alone Node Setup

Stand-Alone Node Setup

Stand-Alone Installation Testing

6 Stand-Alone Installation Testing

Part III: Network Turn-Up and Testing

Connecting Adjacent Network Elements

Connecting Adjacent Network Elements

WDMX Setup and Testing: Integration Procedures

WDMX Setup and Testing: Integration Procedures

Part IV: Miscellaneous Detailed Installation Procedure and Reference Material

Fiber Cleaning

Fiber Cleaning

Pluggable Transmission Module (PTM) Installation

B Pluggable Transmission Module (PTM) Installation

C Installing Fiber Connectors and Lbos

D Backplane Pin Replacement

Backplane Pin Replacement

Fiber Labeling

Glossary

Terms and Definitions

Quick Links

Related Manuals for Alcatel-Lucent 1665

Summary of Contents for Alcatel-Lucent 1665
