Function Menu
Cover / Pressure
Ribbon encoder winder
Ribbbon encoder
unwinder
Carriage sensors
Material encoder
Carriage sensor left
Carriage sensor right
Counter ribbon
encoder rewinder
Counter ribbon
encoder unwinder
Material encoder
counter
96

10.19 Service Functions

10.19.1 Sensor Status

Cover: Only available at devices with cover switch.
Indication of value 0 or 1 for cover open and/or cover closed
Pressure: Indication of value 0 or 1 or compressed air control.
Indication of value 0 to 3 for the status of transfer ribbon rewinding
roll. Indication of transfer ribbon rewinding roll status.
4 states are indicated (no marking in photocell, marking from right,
marking from left, marking completely in photocell).
Indication of value 0 to 3 for the status of transfer ribbon unwinding
roll. Indication of transfer ribbon unwinding roll status.
4 states are indicated (no marking in photocell, marking from right,
marking from left, marking completely in photocell).
Indication of print carriage position.
Indication of current state of encoder
Verifies the left stop of printing carriage.
Verifies the right stop of printing carriage.
In the case of a full rotation of the transfer ribbon encoder rewinder,
the counter should be increased/decreased by the second value
(depending on the direction of rotation). If this is not the case, there
may be a problem with the sensor.
In the case of a full rotation of the transfer ribbon encoder unwinder,
the counter should be increased/decreased by the second value
(depending on the direction of rotation). If this is not the case, there
may be a problem with the sensor.
Indication of counter status of encoder.
