Maintenance and Cleaning
126

12.2 Clean the Transfer Ribbon Roller

A soiled ribbon roller can lead to reduced print quality and can affect
transport of material.
A
Figure 23
1. Remove the transfer ribbon cassette.
2. Remove deposits with the roller cleaner and a soft cloth.
3. If the roller (A) appears damaged, replace it.

12.3 Clean the Printhead

Printing can cause accumulation of dirt at printhead e.g. by colour
particles of transfer ribbon, and therefore it is necessary to clean the
printhead in regular periods depending on operating hours,
environmental effects such as dust etc.
CAUTION!
Printhead can be damaged!

Do not use sharp or hard objects to clean the
printhead.

Do not touch protective glass layer of the printhead.
1. Remove the transfer ribbon cassette.
2. Clean the printhead surface with a special cleaning pen or a
cotton swab dipped in pure alcohol.
3. Before using the printing system, let the printhead dry for about
two to three minutes.
