Dynacode II IP
Ribbon saving
STANDARD
Max. print speed
Max. print speed
Ribbon correction
Example
03.21

10.10.4 General Parameters

Maximum ribbon saving performance, i.e. with this setting there is no
loss of transfer ribbon (apart from the safety distance of 1 mm, so the
print fields are not printed one into the other).
No settings are allowed with which the ribbon saving no more cannot
be achieved. This particularly applies for the print offset, which can
only be adjusted now in the valid range.
Determination of max. print speed.
On the base of this value all necessary calculations e.g. feedback
distance and smallest possible print offset are being calculated.

10.11 Ribbon Saving SHIFT (Continuous Mode)

10.11.1 Required Parameters

Determination of max. print speed.
On the base of this value all necessary calculations e.g. feedback
distance and smallest possible print offset are being calculated.
0 mm = It is always so far retracted that an optimal ribbon saving is
reached (no loss of transfer ribbon). This is rather rarely realised, as
the ribbon position can deviate because of inaccuracies at speed
measurement (encoder).
Default: -1 mm
−xx mm = The feedback can be made smaller. It causes loss of
transfer ribbon but the number of cycles is increased. If the value is
increased to the complete backfeed length then the direct print
module sets automatically the max. value and no more backfeed is
accomplished.
+xx mm = The feedback can be made larger. This causes that it is
printed onto the transfer ribbon in the previous printout.
