Function Menu
I/O status input
I/O status output
I/O test output
I/O status test output
Encoder profile
Last print min. speed*
Last print max. speed*
100
Indication of input signal level
0 = Low
1 = High
Indication of output signal level
0 = Low
1 = High
Quick selection of the required output. Then the signal level must be
selected with I/O status test output.
Selection of the output signal level previously selected under I/O test
output.
0 = Low
1 = High

10.19.6 Encoder Service

The encoder values with print start in logging files are registered on
CF card. By means of this data, a graphic chart of the encoder curve
can be created.
For further information please contact our support department.
Indicates the speed fluctuation within one layout measured by the
rotary encoder.
Measured minimum speed of the last layout.
Indicates the speed fluctuation within one layout measured by the
rotary encoder.
Measured maximum speed of the last layout.
* continuous mode only
