Installation and Initial Operation
42

7.8 Print Control

As the direct print module is always in control mode, print orders can
only be transmitted but not started via the existing interfaces (serial,
parallel, USB or Ethernet). The print is started by a start signal to the
'print start-control input'. So that the control unit detects when the start
signal can be set, it is possible and mostly necessary to track the print
status via the control outputs.

7.9 Initial Operation

After all connections are completed, switch on the control unit.
Insert the ribbon cassette (see chapter 8, page 43).
After loading the transfer ribbon cassette the measuring of
transfer ribbon begins and the printhead is moved to the print
position.
Operating Manual
Dynacode II IP
03.21
