Dynacode II IP
Paper counter
printhead
Paper counter machine
Heater resistance
Printhead temperature
Mechanics temperature
Online / Offline
03.21

10.19.2 Device Status

Indication of printhead attainment in meters.
Indication of direct print module attainment in meters.
To achieve a high print quality, the indicated Ohm value must be set
after replacing the printhead.
Indication of printhead temperature. The printhead temperature
corresponds normally to the room temperature. In case the maximum
printhead temperature is exceeded, the current print order is
interrupted and an error message appears at the direct print module
display.
Indication of print mechanics temperature.
This function is activated e.g. if the transfer ribbon is to be changed. It
is avoided that a print order is processed although the module is not
ready. The respective state is indicated in the display.
Standard: Off
Online: Data can be received by interface.
Offline: The keys of the foil keyboard are still active but received data
are not processed. If the module is again in Online mode then new
print orders can be again received.
