Technical Data
List of registered
functions for
StdFileSelDirect
28
Port Function
11 (Input) Print start
12 (Input) Error reset
13 (Input)* Number of the file to load Bit 0 (Input)
14 (Input)* Number of the file to load Bit 1 (Input)
15 (Input)* Number of the file to load Bit 2 (Input)
16 (Input)* Number of the file to load Bit 3 (Input)
17 (Input)* Number of the file to load Bit 4 (Input)
18 (Input)* Number of the file to load Bit 5 (Input)
19 (Output) Error
10 (Output) Active print order
11 (Output) Generation
12 (Output) Printing
13 (Output) Ready
14 (Output) Error
15 (Output) Return
16 (Output) Transfer ribbon prior warning
* The files must be saved onto the CF card in the user directory.
The files must start with one or two digits (1_Etikett.prn,
02_Etikett.prn).
The files can be saved with a file extension.
In the printer status 'ready', 'waiting' or 'stop', a new file can be loaded.
The printer order will be started after charging and an already existing
printer order will be deleted.
The input signal 000000 does not charge a file and does not delete an
already existing print order.
