Technical Data
Technical data
30
Plug Connector
Type
Manufacturer
Reference number
Output Voltages (connected with GND-PE)
+ 24 V / 1 A
+ 5 V / 1 A
Port 1 - 15
Input
Tension
Impedance
Output
Tension
Impedance
Current max.
Port 16
Input
Tension
Impedance
Output
Tension
Impedance
Current max.
Optocoupler
Output
Input
Input
Option 2nd LED
Operating Manual
D-Sub connector High Density
26-pin. / connector
W+P-Products
110-26-2-1-20
Fuse: Polyswitch / 30 V / 1 A
Fuse: Polyswitch / 30 V / 1 A
5 VDC ... 24 VDC
47Ω + (100nF || 10 kΩ)
5 VDC ... 24 VDC
47Ω + (100nF || 10 kΩ || 47Ω)
High +15 mA
Low -15 mA
5 VDC ... 24 VDC
100nF || 10 kΩ
5 VDC ... 24 VDC
100nF || 10 kΩ
High +500 mA (Darlington BCP56-16)
Low - 500 mA (Darlington BCP56-16)
TCMT4106, CTR 100 % - 300 %, Vishay or
TLP281-4(GB), CTR 100 % - 600 %,
Toshiba
TCMT4106, CTR 100 % - 300 %, Vishay or
TLP281-4(GB), CTR 100 % - 600 %,
Toshiba
TCMT4600, CTR 80 % - 300 %, Vishay or
TLP280-4, CTR 33 % - 300 %, Toshiba
