Dynacode II IP
Port 1 to Port 16 = Assignment for I/O Profile Std_Direct
Port Pin
11 (Input) 10
12 (Input) 1
13 (Input) 11
14 (Input) 2
15 (Input) 12
16 (Input) 3
17 (Input) 13
18 (Input) 4
19 (Output) 15
10 (Output) 6
11 (Output)
16
12 (Output)
7
13 (Output)
17
14 (Output)
8
15 (Output)
18
16 (Output)
9
COM/VDC 19
for Inputs
VDC for 20
Outputs
COM for 5,14
Outputs
21,22
GND-PE 23,24
03.21
Description / Function
Print start
No function
Counter reset
No function
Error reset
No function
No function
No function
Error
No function
No function
Printing
Ready
No function
Return printing carriage
Transfer ribbon prior warning
Common reference potential of all control inputs. 'COM/VDC for Inputs' is
usually connected with the (-) terminal of the control voltage and the
control inputs are switched to active (+).
By means of the option '2nd LED', 'COM/VDC for Inputs' can optionally be
connected with the (+) terminal of the control voltage. Then, the control
inputs are switched to active (-).
Common supply connection of all control outputs. 'VDC for Outputs' must
be connected with the (+) terminal of the control voltage.
Never leave 'VDC for Outputs' open even if no output is used.
Common reference potential of all control outputs. 'COM for Outputs' must
be connected with the (-) terminal of the control voltage.
Never leave 'COM for Outputs' open even if no output is used.
'GND-PE' is the reference potential of the '+5 VDC EXT' and '+24 VDC
EXT' voltages provided by the printer system.
'GND-PE' is printer internally connected with protective earth (PE).
