Dynacode II IP
Printhead down time
Ribbon motor early
start time
Min. print speed
Minimization print
offset
Printhead valve
react time
Field ribbon saving
mode
Ribbon saving priority
Save start signal
03.21

10.11.3 Expert Parameters

This is used from ribbon saving algorithm for the calculation of start
time of printhead downwards movement.
This value is added to the acceleration time of transfer ribbon
movement. Time indication for the time between 'motor reached
material speed' and 'printhead burns'.
If the same value is entered as for PhDownT, the printhead upwards
movement is not started before the transfer ribbon motor reached the
material speed.
If the min. print speed is increased, the max. number of cycles is also
increased.
The smallest possible print offset is automatically set in the menu
Machine parameters/Print offset.
On: The print offset value range is set to the smallest possible value
that can be achieved with the current settings (e.g. print speed).
Off: The print offset value range remains at the default setting.
It is calculated when the printhead upwards movement is started.
Off: Field ribbon saving mode Off.
PHOnly: Only the printhead is moved. The transfer ribbon is not
stopped.
Normal: Field ribbon saving is executed only if the transfer ribbon
motor is completely stopped.
Strong: Field ribbon saving is executed, even if the transfer ribbon
motor is not stopped.
If the measured speed fluctuation of the material exceeds the
processing capability of the printing system, either the optimisation
may be reduced, or the print position shifted.
The "SaveStrt" optimisation mode already exists. If a start signal is
active during an active print, the transfer ribbon transport is controlled
in such a way that the next layout is printed directly after completion of
offset travel of the last start signal. To achieve this, however, an
optimisation with transfer ribbon retraction is not possible.
To enable a start signal during printing with retraction, this option can
be enabled. In this case, however, sufficient print offset for transfer
ribbon retraction must be ensured.
