9.2 Use the Cleaning Cassette

1. Remove the transfer ribbon cassette necessary for printing
(see chapter 8, page 43.
2. Push and lock the cleaing cassette in the same way.
3. By an inserted sealing profile (A, Figure 22) and a cover (B,
Figure 23) the print mechanics is protected in such a way for
ingress of water and dust.
4. The pneumatic tube and the connection cables to the control unit
with the waterproof housings may not be removed.
5. Indications for maintenance and cleaning are described in chapter
12, page 125.
6. Before the resumption of printing the cleaning cassette must be
changed again with the transfer ribbon cassette.
CAUTION!
The direct print module can be damaged by ingress of water
due to incorrect operation/locking.

After removing the cleaning cassette examine the print
mechanics for ingress of water.

Before the device is again taken into operation, dry the
approriate place well.
