Function Menu
Number of columns
Material
Flip layout
Rotate layout
Alignment
Print length
Layout width
64

10.6 Layout Settings

10.6.1 Extended Layout Settings

Indication of width of one layout as well as how many layouts are
placed side by side on the backing paper.
With this print module, several columns can be printed, i.e. the
information of one column can be printed several times (depending on
its width) on a layout. Caused by this the use of the complete print
width is possible and the generating time is enormously reduced.
Selection of the used transfer ribbon material.
The axis of reflection is in the middle of the layout. If the layout width
was not transferred to the direct print module, automatically the
default layout width i.e. the width of the printhead is used. It is
recommended to use layouts with the same width as the printhead.
Otherwise this can cause problems in positioning.
According to standard the layout is printed ahead with a rotation of 0°.
If the function is activated, the layout is rotated by 180° and printed in
reading direction.
The adjustment of layout is effected only after Flip/Rotate layout, i.e.
the adjustment is independent of the functions Flip layout and Rotate
layout.
Left = The layout is aligned at the left-most position of printhead.
Centre = The layout is aligned at central point of printhead.
Right = The layout is aligned at right-most position of printhead.

10.6.2 General Parameters

Indication of the print length in mm.
Indication of way the print mechanics has to move. The print length
depends on the length of the print mechanics.
Indication of the layout width in mm.
