Installation and Initial Operation
38
1. Successively remove the four screws (C) on the back on the
control unit (A), slide on the sealing rings (B) and screw in the
screws (C) again.
2. Guide the connection cable print mechanics/control unit (F) with
the non-sealed side from the outside through the protective cover
(G).
3. Connect the connection cable print mechanics/control unit (F) to
the control unit (A).
4. If necessary, connect a connection cable for external
inputs/outputs to the appropriate socket of the control unit (A).
5. If necessary, connect an Ethernet or USB data cable to the control
unit (A).
6. Insert the USB data cable (E) on the inside of the protective cover
(E) into the USB socket.
7. Guide the power cable (D) and if necessary, the data and I/O
cable through the opening of the protective cover (G).
8. Guide the protective cover (G) in the direction of the control unit
(A) until the USB data cable (E) can be connected to the control
unit (A).
9. Screw the protective cover (G) to the control unit (A) with the four
screws (I) and the sealing rings (H).
10. Remove the upper part of the cable entry strip (K) after removing
the both screws (J).
11. Remove the cable grommets (M) that fit to the respective
connection cables from the cable entry strip (K) and enclose the
cables two to three centimeters in front of the protective cover (G).
12. Place the cable entry strip (K) in front of the protective cover and
insert the cable grommets (M) with connection cables into the
slots. The connection cables print mechanics/control unit (F) must
be placed in the upper left corner and the power cable (D) should
be placed on the bottom left (see Figure 17).
NOTICE!
The side of the cable entry strip (K) with the seal injected
must point in the direction of the protective cover (G).
The smooth, even sides of the grommets (M) must face
each other in the middle of the entry strip.
Unnecessary cable grommets (M) must be closed with the
enclosed suitable plugs (N).
13. Fix the upper part of the cable entry strip (K) with the screws (J),
so that the connecting cables are still movable.
14. Fix the cable entry strip (K) to the protective cover (G) with the
screws (L).
15. Screw tight the upper part of the cable entry strip (K).
