Carl Valentin DYNACODE II IP53 Operating Manual page 22

Ingress protection version
Hide thumbs Also See for DYNACODE II IP53:
Table of Contents

Advertisement

Technical Data
Operation Data
Ingress Protection Rating
Temperature
Humidity
Operation Panel
Touchscreen display
Operating functions
Settings
Monitoring
Stop printing if
Status report
Fonts
Font types
Character sets
Bitmap fonts
Vektor fonts/
TrueType fonts
Font attributes
Font width
Bar Codes
1D bar codes
2D bar codes
Composite bar codes
Software
Configuration
Process control
Design software
Windows printer driver
Technical details are subject to change.
22
IP 65
5 ... 40 °C
max 80 % (non-condensing)
Colour display: 800 x 480 pixel, screen size 7"
favorites, function menu, memory card, print start, test print, feed,
about menu
date, time, shift times
11 language settings (others on demand)
print and device parameters, interfaces, password protection
end of ribbon / end of layout
extensive status print with information about settings e.g. print length
counter, runtime counter, photocell interface and network parameters
printout of all internal fonts and all supported bar codes
6 Bitmap fonts, 8 Vector fonts/TrueType fonts, 6 proportional fonts
other fonts on demand
Windows 1250 up to1257, DOS 437, 850, 852, 857
all West and East European Latin, Cyrillic, Greek
and Arabic (option) characters are supported
other character sets on demand
size in width and height 0,8 ... 5,6
zoom 2 ... 9, orientation 0°, 90°, 180°, 270°
size in width and height 1 ... 99 mm
variable zoom
orientation 0°, 90°, 180°, 270°
depending on character font - bold, Italic, inverse, vertical
variable
CODABAR, Code 128, Code 2/5 interleaved, Code 39, Code 39
extended, Code 93, EAN 13, EAN 8, EAN ADD ON, GS1-128,
Identcode, ITF 14, Leitcode, Pharmacode, PZN 7 Code, PZN 8 Code,
UPC-A, UPC-E
Aztec Code, CODABLOCK F, DataMatrix, GS1 DataMatrix,
MAXICODE, PDF 417, QR Code
GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar
Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked
Omnidirectional, GS1 DataBar Truncated
all bar codes are variable in height, module width and ratio.
orientation 0°, 90 °, 180°, 270°.
Optionally with check digit and human readable line.
ConfigTool
NiceLabel
Labelstar Office Lite, Labelstar Office
®
Windows 7
- Windows 10
Windows Server 2008
Operating Manual
®
32/64 Bit,
®
(R2) - Windows Server 2019
Dynacode II IP
®
03.21
