Dynacode II IP
COM1 mode
Baud rate
Parity
Data bits
Stop bits
SOH/ETB
Data memory
Port test
03.21

10.16 Interface

10.16.1 COM1

Off: serial interface Off
On (mode 1): serial interface On
On (mode 2): serial interface On; no error message appears in case
of a transmission error
Indication of bits which are transferred per second (speed of data
transfer).
Value range: 1200, 2400, 4800, 9600, 19200, 38400, 57600 and
115200.
None: No parity
Even: Even parity
Odd: Odd parity
Setting of data bits.
Value range: 7 or 8 Bits.
Indication of stop bits between bytes.
Value range: 1 or 2 stop bits.

10.16.2 General Parameters

SOH: Start of data transfer block
ETB: End of data transfer block
Two different start / en signs can be set. The settings are normally
SOH = 01 HEX and ETB = 17 HEX. Several host computers cannot
process these signs and therefore SOH = 5E HEX and ETB = 5F
cannot be set.
Off: After starting a print order no more data is received.
Standard: After starting a print order the printer buffer receives data
as long as it is filled.
Advanced: During a current print order data is received and
processed.
Check whether the data are transferred via the interface.
Operating Manual
Function Menu
Hex format 01
Hex formal 17
