Dynacode IP Series
Photocell parameters
Laufleistung
Heater resistance
08.16
12.16 Service Functions
NOTICE!
So that the distributor res. the direct print module manufacturer
in case of service can offer fast support all necessary
information such as selected parameters can be taken directly
from the device.
Switch on the direct print module and the display shows the main
menu.
Press key
to access the function menu.
Press key
as long as you arrive the Service Functions menu.
Press key
to select the menu.
H
= Cover switch
Only available at devices with cover switch.
0 = oper cover
1 = closed cover
P
= Pressure
Indication of value 0 or 1 or compressed air control.
R1
= Transfer ribbon rewinding roll
Indication of transfer ribbon rewinding roll status.
4 states are indicated (no marking in photocell, marking from
right, marking from left, marking completely in photocell).
R2
= Transfer ribbon unwinding roll
Indication of transfer ribbon unwinding roll status.
4 states are indicated (no marking in photocell, marking from
right, marking from left, marking completely in photocell).
C
= Carriage
Indication of print carriage position.
ENC = Encoder
Indication of current state of encoder
Press key
to arrive the next menu item.
D: Indication of printhead attainment in meters.
G: Indication of direct print module attainment in meters.
Press key
to arrive the next menu item.
To achieve a high print quality, the indicated Ohm value must be set
after an exchange of printhead.
Operating Manual
Function Menu
69
