Dynacode II IP
External parameters
Field handling
Customized entry
03.21

10.7 Device Settings

10.7.1 Print Job

Layout dimension only: The parameters for layout length, gap
length and layout width can be transferred to the printing system. All
other parameter settings are to be made directly at the printing
system.
On: Sending parameters such as speed and contrast via our design
software to the printing system. Parameters which are set directly at
the printing system before are no longer considered.
Off: Only settings made directly at the printing system are considered.
Off: The complete print memory is deleted.
Keep graphic: A graphic res. a TrueType font is transferred to the
direct print module once and stored in the direct print module internal
memory. For the following print order only the modified data is
transferred to the direct print module. The advantage is the saving of
transmitting time for the graphic data.
The graphic data created by the direct print module itself (internal
fonts, bar codes, ...) is generated only if they were changed. The
generating time is saved.
Delete graphic: The graphics res. TrueType fonts stored in the
internal memory is deleted but the other fields are kept.
Restore graphic: At the end of the print order the printed order can
again be started at the direct print module. All graphics and TrueType
fonts are again printed.
NOTICE!
Exception: With column printing always full columns must be
printed (number of pieces always multiple of the columns).
Deleted columns are not restored.
Off: No question appears at the display. In this case the stored default
value is printed.
On: The question referring the customized variable appears once
before the print start at the display.
Auto: The questions referring the customized variable and the
quantity query appear after every printed layout.
Auto without quantity query: The question referring the customized
variable appears after every layout without additional query for the
quantity.
