Dynacode II IP
Current diameters
Brake power
Brake power print
PrtStrtIntsReal
PrtStrtIntsDebounced
PrtStrtIntsNoPrint
PrtStrtReset
PrtStrtTime
03.21
Diameter ribbon rewinder: Indication how much transfer ribbon is
already on the rewinding roll, i.e. how much transfer ribbon was
already used.
Diameter ribbon unwinder: Indication how much transfer ribbon is
still on the unwinding roll.
Remaining roll length: Indication how much transfer ribbon in meters
is still on the ribbon roll available.
Roll diameter: Indication how much transfer ribbon is still on the
transfer ribbon roll. For a correct display some layouts must be
reprinted.
Time left: Indication during a current print order, how long it can be
printed with the existing transfer ribbon.

10.19.4 Brake Service

Adjustment of brake power for acceleration and braking in %.
Adjustment of brake power during printing.

10.19.5 I/O Status

The start input impulses are counted directly at the Interrupt.
The start input impulses that are longer than the set debounce time
are counted. Only these start impulses can lead to a print. If a start
impulse is too short, no print is released. This is recognized by the fact
that RInt is counted, Dbnc not.
The debounced start input impulses that have not led to a print are
counted. Causes: no active print order, print order stopped (manually
or because of an error) or the printing system is still active with the
processing of a print order.
The counters are reset.
Measured length of the last start impulse in ms.
