Function Menu
Operating mode
60

10.4 Machine Parameters (Continuous Mode)

The print procedure cannot be started via the interface. The machine
is always in control mode and the print is released by the control input
Print Start. The operating mode is normally transferred with each
layout otherwise mode I/O dynamic continuous is used as standard
operating mode.
The following modes are available:
IO static:
The input signal is evaluated, i.e. it is printed as long as the signal
exists. The number of layouts, which was entered at print start, is
printed (level evaluation of print start signal).
IO static continuous:
Corresponds to IO static. Continuous means that not only a defined
number of pieces is processed but the same layout is printed as long
as new data is transferred by interface.
IO dynamic:
The external signal is evaluated dynamically, i.e. in case the direct
print module is in 'waiting' mode a single layout is printed at each
signal changing (flank evaluation of print start signal).
IO dynamic continuous:
Corresponds to IO dynamic. Continuous means that not only a
defined number of pieces is processed but the same layout is printed
as long as new data is transferred by interface.
