Function Menu
Operating mode
Back speed
62

10.5 Machine Parameters (Intermittent Mode)

Number of pieces:
A print order with a defined number of pieces is transferred. After the
generating process the target number and the actual number of
pieces is shown in the display. A cycle is started via signal input 1.
With each cycle the actual number of pieces is increased by the
number of printed layouts. In case the target number of pieces is
reached the print order is finished and the display shows again the
main menu.
Continuous:
A print order is transferred. After the generating process the number
of printed layouts is shown in the display. A cycle is started via signal
input 1. With each cycle the number of printed layouts is increased.
The print order is active as long as it is terminated by the user or in
case of new data transmission.
Test mode:
This operating mode corresponds to mode 2. After the return of the
print unit to the zero point of the machine, however, internally a further
cycle is started (endurance test).
Direct start:
A print order is transferred. After termination of generating process the
print order is executed without an external signal.
Indication of back speed of print mechanics after print end in mm/s.
Each cycle of the machine consists of printing and return to the zero
point of machine. The print speed and back speed can be set
separately.
Because of this value you can select for low machine clock cycles an
operating method which saves the material and increases in this way
the life of the printhead.
Because of the mass moment of inertia, it could be better to reduce
the speed at an installation position of the print unit at >30° horizontal.
Value range: 50 ... 600 mm/s.
