Dynacode II IP
List of registered
functions for
Std_Direct
List of registered
functions for
Std_Direct2
03.21

6.2 Registered Functions/Profiles for Inputs/Outputs

Select menu I/O Parameters / I/O Profile to select the desired profile.
Port Function
11 (Input) Print start
12 (Input) Error reset
13 (Input) Counter reset
14 (Input) Release signal
15 (Input) No function
16 (Input) No function
17 (Input) No function
18 (Input) No function
19 (Output) Error
10 (Output) Active print order
11 (Output) Generation
12 (Output) Printing
13 (Output) Ready
14 (Output) Error
15 (Output) Return
16 (Output) Transfer ribbon prior warning
Port Function
11 (Input) Print start
12 (Input) Error reset
13 (Input) Counter reset
14 (Input) Release signal
15 (Input) No function
16 (Input) No function
17 (Input) No function
18 (Input) No function
19 (Output) Error
10 (Output) Ready
11 (Output) Cassette open
12 (Output) Printing
13 (Output) Return
14 (Output) Printhead down
15 (Output) Print position
16 (Output) Transfer ribbon prior warning
