Dynacode II IP
Print examples
Device operating mode
Write log files to
memory card
Delete print job and
spool file
03.21

10.19.7 General Parameters

Settings: Printout of all device settings such as speed and transfer
ribbon material.
Bar codes: Printout of all available bar code types.
Fonts: Printout of all available font types.
Define whether the printing system is used in continuous mode (see
page 13) or in intermittent mode (see page 15).
Starting with firmware version 1.70, the printer logs different events
internally. In case of service, the error cause can be located faster.
With this command, different log files are saved on an existing storage
medium (memory card or USB stick). After the 'Finish' message the
storage medium can be removed.
The files are in directory 'log':
LogMemErr.txt: Logged errors with additional information such as
date/time and file name/line number (for developers).
LogMemStd.txt: Logging of selected events.
LogMemNet.txt: Data latest send via port 9100.
Parameters.log: All printer parameters in human readable form.
TaskStatus.txt: Status of all printer tasks.
The files LogMemErr.txt and LogMemStd.txt are written in circle, i.e.
old contents are overwritten. The entry logged last is marked with „---„
The current print order and all pending print orders are deleted.

10.20 Password

With a password different functions can be blocked for the operator.
There are different applications with which such a password protection
can be used reasonably. To receive a most flexible password
protection, the printing system functions will be divided into several
function groups.
Because of these different function groups, the password protection is
very flexible. The printing system can be adjusted best to its actual
order, as only certain functions are blocked.
Operating Manual
Function Menu
101
