Danfoss VLT FC 100 Series Programming Manual page 35

Parameter Description
0-20 Display Line 1.1 Small
Option:
[1837] Temp. Input
3 3
X48/4
[1838] Temp. Input
X48/7
[1839] Temp. Input
X48/10
[1850] Sensorless
Readout [unit]
[2117] Ext. 1 Reference
[Unit]
[2118] Ext. 1 Feedback
[Unit]
[2119] Ext. 1 Output [%]
[2137] Ext. 2 Reference
[Unit]
[2138] Ext. 2 Feedback
[Unit]
[2139] Ext. 2 Output [%]
[2157] Ext. 3 Reference
[Unit]
[2158] Ext. 3 Feedback
[Unit]
[2159] Ext. 3 Output [%]
[2230] No-Flow Power
[2316] Maintenance Text
[2580] Cascade Status
[2581] Pump Status
[3110] Bypass Status
Word
[3111] Bypass Running
Hours
[9913] Idle time
[9914] Paramdb requests
in queue
[9920] HS Temp. (PC1)
[9921] HS Temp. (PC2)
[9922] HS Temp. (PC3)
[9923] HS Temp. (PC4)
[9924] HS Temp. (PC5)
3-8
®
VLT HVAC Drive Programming Guide
Function:
The value of the reference for
extended Closed-loop Controller 1
The value of the feedback signal for
extended Closed-loop Controller 1
The value of the output from
extended Closed-loop Controller 1
The value of the reference for
extended Closed-loop Controller 2
The value of the feedback signal for
extended Closed-loop Controller 2
The value of the output from
extended Closed-loop Controller 2
The value of the reference for
extended Closed-loop Controller 3
The value of the feedback signal for
extended Closed-loop Controller 3
The value of the output from
extended Closed-loop Controller 3
The calculated No-Flow Power for
the actual operating speed
Status for the operation of the
Cascade Controller
Status for the operation of each
individual pump controlled by the
Cascade Controller
MG11CD22 - VLT ®
0-20 Display Line 1.1 Small
Option:
[9925] HS Temp. (PC6)
[9926] HS Temp. (PC7)
[9927] HS Temp. (PC8)
0-21 Display Line 1.2 Small
Select a variable for display in line 1, middle position.
Option:
[1614] Motor Current The options are the same as those listed
*
0-22 Display Line 1.3 Small
Select a variable for display in line 1, right position.
Option:
[1610] Power [kW] The options are the same as those listed in
*
0-23 Display Line 2 Large
Select a variable for display in line 2.
Option: Function:
[1613] Frequency The options are the same as those listed in
*
0-20 Display Line 1.1 Small.
0-24 Display Line 3 Large
Select a variable for display in line 3.
Option:
[30121] Mains Frequency The options are the same as those
*
0-25 My Personal Menu
Array [20]
Range:
Size related
*
3.2.4 0-3* LCP Custom Readout
It is possible to customize the display elements for various
purposes: *Custom Readout. Value proportional to speed
(linear, squared or cubed depending on unit selected in
0-30 Custom Readout Unit) *Display Text. Text string stored
in a parameter.
Custom Readout
The calculated value to be displayed is based on settings
in 0-30 Custom Readout Unit, 0-31 Custom Readout Min
Value (linear only), 0-32 Custom Readout Max Value,
4-13 Motor Speed High Limit [RPM], 4-14 Motor Speed High
Limit [Hz] and actual speed.
is a registered Danfoss trademark
Function:
Function:
in 0-20 Display Line 1.1 Small.
Function:
0-20 Display Line 1.1 Small.
Function:
listed in 0-20 Display Line 1.1 Small.
Function:
[0 - 9999 ]
