Parameter Description
13-51 SL Controller Event
Array [20]
Option:
3 3
[18] Reverse
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Timeout 0
[31] SL Timeout 1
[32] SL Timeout 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Timeout 3
[71] SL Timeout 4
[72] SL Timeout 5
[73] SL Timeout 6
[74] SL Timeout 7
[76] Digital Input x30 2
[77] Digital Input x30 3
[78] Digital Input x30 4
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive Mode
3-88
®
VLT HVAC Drive Programming Guide
Function:
MG11CD22 - VLT ®
13-51 SL Controller Event
Array [20]
Option:
[91] ECB Bypass Mode
[92] ECB Test Mode
[100] Fire Mode
13-52 SL Controller Action
Array [20]
Option:
[0] DISABLED
*
[1] No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
[15] Select preset ref 5
[16] Select preset ref 6
[17] Select preset ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
is a registered Danfoss trademark
Function:
Function:
Select the action corresponding to the
SLC event. Actions are executed when
the corresponding event (defined in
13-51 SL Controller Event) is evaluated
as true. The following actions are
available for selection:
Changes the active set-up (0-10 Active
Set-up) to '1'.
Changes the active set-up (0-10 Active
Set-up) to '2'.
Changes the active set-up (0-10 Active
Set-up) to '3'.
Changes the active set-up (0-10 Active
Set-up) to '4'. If the set-up is changed,
it will merge with other set-up
commands coming from either the
digital inputs or via a serial communi-
cation bus.
Selects preset reference 0.
Selects preset reference 1.
Selects preset reference 2.
Selects preset reference 3.
Selects preset reference 4.
Selects preset reference 5.
Selects preset reference 6.
Selects preset reference 7. If the active
preset reference is changed, it will
merge with other preset reference
commands coming from either the
digital inputs or via a serial communi-
cation bus.
Selects ramp 1
Selects ramp 2
Issues a start command to the
Adjustable frequency drive.
