Parameter Description
13-01 Start Event
Option: Function:
[16] Thermal warning See parameter group 5-3* for further
description.
[17] Mains out of range See parameter group 5-3* for further
description.
[18] Reverse See parameter group 5-3* for further
description.
[19] Warning See parameter group 5-3* for further
description.
[20] Alarm (trip) See parameter group 5-3* for further
description.
[21] Alarm (trip lock) See parameter group 5-3* for further
description.
[22] Comparator 0 Use the result of comparator 0 in the
logic rule.
[23] Comparator 1 Use the result of comparator 1 in the
logic rule.
[24] Comparator 2 Use the result of comparator 2 in the
logic rule.
[25] Comparator 3 Use the result of comparator 3 in the
logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the
logic rule.
[27] Logic rule 1 Use the result of logic rule 1 in the
logic rule.
[28] Logic rule 2 Use the result of logic rule 2 in the
logic rule.
[29] Logic rule 3 Use the result of logic rule 3 in the
logic rule.
[33] Digital input DI18 Use the value of DI18 in the logic rule
(High = TRUE).
[34] Digital input DI19 Use the value of DI19 in the logic rule
(High = TRUE).
[35] Digital input DI27 Use the value of DI27 in the logic rule
(High = TRUE).
[36] Digital input DI29 Use the value of DI29 in the logic rule
(High = TRUE).
[37] Digital input DI32 Use the value of DI32 in the logic rule
(High = TRUE).
[38] Digital input DI33 Use the value of DI33 in the logic rule
(High = TRUE).
[39] Start command This event is TRUE if the Adjustable
frequency drive is started by any
means (either via digital input, serial
communication bus or other).
®
VLT HVAC Drive Programming Guide
13-01 Start Event
Option:
[40]
[41]
[42]
[43]
[44]
[45]
[46]
[47]
[48]
[50]
[51]
[60]
[61]
[76]
[77]
[78]
[90]
[91]
[92]
[100] Fire Mode
13-02 Stop Event
Option:
MG11CD22 - VLT ® is a registered Danfoss trademark
Function:
Drive stopped This event is TRUE if the Adjustable
frequency drive is stopped or coasted
by any means (either via digital input,
serial communication bus or other).
Reset Trip This event is TRUE if the Adjustable
frequency drive is tripped (but not
trip-locked) and the reset button is
pressed.
Auto Reset Trip This event is TRUE if the Adjustable
frequency drive is tripped (but not
trip-locked) and an automatic reset is
issued.
OK Key This event is TRUE if the OK key on
the LCP is pressed.
Reset Key This event is TRUE if the reset key on
the LCP is pressed.
Left Key This event is TRUE if the left key on
the LCP is pressed.
Right Key This event is TRUE if the right key on
the LCP is pressed.
Up Key This event is TRUE if the up key on
the LCP is pressed.
Down Key This event is TRUE if the down key on
the LCP is pressed.
Comparator 4 Use the result of comparator 4 in the
logic rule.
Comparator 5 Use the result of comparator 5 in the
logic rule.
Logic rule 4 Use the result of logic rule 4 in the
logic rule.
Logic rule 5 Use the result of logic rule 5 in the
logic rule.
Digital Input x30 2
Digital Input x30 3
Digital Input x30 4
ECB Drive Mode
ECB Bypass Mode
ECB Test Mode
Function:
Select the Boolean (TRUE or FALSE)
input to deactivate Smart Logic
Control.
