5.1.22 24-** Application Functions 2

Par. Parameter description
No. #
24-0* Fire Mode
24-00 Fire Mode Function
24-01 Fire Mode Configuration
24-02 Fire Mode Unit
5 5 24-03 Fire Mode Min Reference
24-04 Fire Mode Max Reference
24-05 Fire Mode Preset Reference
24-06 Fire Mode Reference Source
24-07 Fire Mode Feedback Source
24-09 Fire Mode Alarm Handling
24-1* Drive Bypass
24-10 Drive Bypass Function
24-11 Drive Bypass Delay Time
24-9* Multi-Motor Funct.
24-90 Missing Motor Function
24-91 Missing Motor Coefficient 1
24-92 Missing Motor Coefficient 2
24-93 Missing Motor Coefficient 3
24-94 Missing Motor Coefficient 4
24-95 Locked Rotor Function
24-96 Locked Rotor Coefficient 1
24-97 Locked Rotor Coefficient 2
24-98 Locked Rotor Coefficient 3
24-99 Locked Rotor Coefficient 4
Table 5.23
5-26
®
VLT HVAC Drive Programming Guide
Default value
(SR = Size related)
[0] Disabled
[0] Open-loop
ExpressionLimit
ExpressionLimit
ExpressionLimit
0.00 %
[0] No function
[0] No function
[1] Trip, Critical Alarms
[0] Disabled
0 s
[0] Off
0.0000 N/A
0.0000 N/A
0.0000 N/A
0.000 N/A
[0] Off
0.0000 N/A
0.0000 N/A
0.0000 N/A
0.000 N/A
MG11CD22 - VLT ® is a registered Danfoss trademark
4 set-up Change Conver-
during sion index
operation
2 set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
2 set-ups FALSE
2 set-ups TRUE
2 set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
- Uint8
- Uint8
- Uint8
-3 Int32
-3 Int32
-2 Int16
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint16
- Uint8
-4 Int32
-4 Int32
-4 Int32
-3 Int32
- Uint8
-4 Int32
-4 Int32
-4 Int32
-3 Int32
