9-16 PCD Read Configuration
Array [10]
Option:
3 3
[1639] Control Card Temp.
[1650] External Reference
[1652] Feedback [Unit]
[1653] Digi Pot Reference
[1654] Feedback 1 [Unit]
[1655] Feedback 2 [Unit]
[1656] Feedback 3 [Unit]
[1660] Digital Input
[1661] Terminal 53 Switch Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch Setting
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1667] Freq. Input #29 [Hz]
[1668] Freq. Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1684] Comm. Option STW
[1685] Drive Port CTW 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1696] Maintenance Word
[1830] Analog Input X42/1
[1831] Analog Input X42/3
[1832] Analog Input X42/5
[1833] Analog Out X42/7 [V]
[1834] Analog Out X42/9 [V]
[1835] Analog Out X42/11 [V]
9-18 Node Address
Range:
126 [
*
126. ]
3-68
Function:
Function:
0 - Enter the station address in this parameter or
alternatively in the hardware switch. In order
to adjust the station address in 9-18 Node
Address, the hardware switch must be set to
126 or 127 (i.e. all switches set to 'on').
MG11CD22 - VLT
®
VLT HVAC Drive Programming Guide
9-18 Node Address
Range:
9-22 Telegram Selection
Option:
[1]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[108]
*
[200]
9-23 Parameters for Signals
Array [1000]
Option:
[0]
*
[302]
[303]
[341]
[342]
[351]
[352]
[380]
[381]
[382]
[411]
[413]
[416]
[417]
[590]
[593]
® is a registered Danfoss trademark
Function:
Otherwise this parameter will display the
actual setting of the switch.
Function:
Select a standard Profibus message
configuration for the adjustable
frequency drive, as an alternative
to using the freely configurable
messages in 9-15 PCD Write Config-
uration and 9-16 PCD Read
Configuration.
Standard telegram 1
PPO 1
PPO 2
PPO 3
PPO 4
PPO 5
PPO 6
PPO 7
PPO 8
Custom telegram 1
None
Minimum Reference
Maximum Reference
Ramp 1 Ramp-up Time
Ramp 1 Ramp-down Time
Ramp 2 Ramp-up Time
Ramp 2 Ramp-down Time
Jog Ramp Time
Quick Stop Ramp Time
Starting Ramp-up Time
Motor Speed Low Limit [RPM]
Motor Speed High Limit [RPM]
Torque Limit Motor Mode
Torque Limit Generator Mode
Digital & Relay Bus Control
Pulse Out #27 Bus Control
Function:
This parameter
contains a list of
signals available for
selection in 9-15 PCD
Write Configuration
and 9-16 PCD Read
Configuration.
