Parameter Description
24-02 Fire Mode Unit
Option: Function:
[40] m / sec.
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
[80] kW
[120] GPM
[121] gal / sec.
[122] gal/min
[123] gal / hr.
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lbs / sec.
[131] lbs / min.
[132] lbs / hr.
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in. wtr. gage
[173] ft WG
[174] in Hg
[180] HP
24-03 Fire Mode Min Reference
Range:
Size related [ -999999.999 - par. 24-04 FireMo-
*
deUnit]
24-04 Fire Mode Max Reference
Range:
Size related [ par. 24-03 - 999999.999 FireMo-
*
deUnit]
24-05 Fire Mode Preset Reference
Range:
0.00 % [-100.00 - 100.00 %]
*
®
VLT HVAC Drive Programming Guide
24-06 Fire Mode Reference Source
Option:
[0]
[1]
[2]
[7]
[8]
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
24-07 Fire Mode Feedback Source
Option:
[0]
[1]
[2]
[3]
[4]
[7]
[8]
[9]
Function:
[10]
[11]
[15]
[100] Bus feedback 1
[101] Bus feedback 2
Function:
[102] Bus feedback 3
Function:
MG11CD22 - VLT ® is a registered Danfoss trademark
Function:
Select the external reference input to
be used for fire mode. This signal will
be added to the value set in
24-06 Fire Mode Reference Source.
No function
Analog input 53
Analog input 54
Pulse input 29
Pulse input 33
Function:
Select the feedback input to be used
for the fire mode feedback signal
when fire mode is active.
If the motor also is controlled by the
built-in PID controller when in
normal operation, the same
transmitter can be used for both
cases by selecting the same source.
No function
*
Analog input 53
Analog input 54
Pulse input 29
Pulse input 33
Analog input X30/11
Analog input X30/12
Analog Input X42/1
Analog Input X42/3
Analog Input X42/5
Analog Input X48/2
3 3
