Parameter Description
10-12 Process Data Config Read
Option:
[1668] Pulse Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1684] Comm. Option Status
[1685] FC Port CTW 1
[1690] Alarm Word
[1691] Alarm word 2
[1692] Warning Word
[1693] Warning word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1696] Maintenance Word
[1830] Analog Input X42/1
[1831] Analog Input X42/3
[1832] Analog Input X42/5
[1833] Analog Out X42/7 [V]
[1834] Analog Out X42/9 [V]
[1835] Analog Out X42/11 [V]
[1850] Sensorless Readout [unit]
10-13 Warning Parameter
Range: Function:
0 [0 - 65535 ] View a DeviceNet-specific warning word. One
*
bit is assigned to every warning. Refer to the
DeviceNet Instruction Manual (MG.33.DX.YY)
for further information.
®
VLT HVAC Drive Programming Guide
Function:
MG11CD22 - VLT ® is a registered Danfoss trademark
Bit: Meaning:
0 Bus not active
1 Explicit connection timeout
2 I/O connection
3 Retry limit reached
4 Actual is not updated
5 CAN bus off
6 I/O send error
7 Initialization error
8 No bus supply
9 Bus off
10 Error passive
11 Error warning
12 Duplicate MAC ID Error
13 RX queue overrun
14 TX queue overrun
15 CAN overrun
Table 3.16
10-14 Net Reference
Read only from LCP
Option: Function:
Select the reference source in instance 21/71 and
20/70.
[0] Off Enables reference via analog/digital inputs.
*
[1] On Enables reference via the serial communication bus.
10-15 Net Control
Read only from LCP
Option: Function:
Select the control source in Instance 21/71 and 20/70.
[0] Off Enables control via analog/digital inputs.
*
[1] On Enable control via the serial communication bus.
3.11.4 10-2* COS Filters
10-20 COS Filter 1
Range: Function:
0 [0 - 65535 ] Enter the value for COS Filter 1 to set up the
*
filter mask for the status word. When
operating in COS (Change-Of-State), this
function filters out bits in the status word that
should not be sent if they change.
3 3
3-75
