Parameter Description
0-20 Display Line 1.1 Small
Option: Function:
[1661] Terminal 53 Setting of input terminal 53. Current
Switch Setting = 0; Voltage = 1.
[1662] Analog Input 53 Actual value at input 53 either as a
reference or protection value.
[1663] Terminal 54 Setting of input terminal 54. Current
Switch Setting = 0; Voltage = 1.
[1664] Analog Input 54 Actual value at input 54 either as
reference or protection value.
[1665] Analog Output 42 Actual value at output 42 in mA.
[mA] Use 6-50 Terminal 42 Output to
select the variable to be
represented by output 42.
[1666] Digital Output Binary value of all digital outputs.
[bin]
[1667] Pulse Input #29 Actual value of the frequency
[Hz] applied at terminal 29 as a pulse
input.
[1668] Pulse Input #33 Actual value of the frequency
[Hz] applied at terminal 33 as a pulse
input.
[1669] Pulse Output #27 Actual value of pulses applied to
[Hz] terminal 27 in digital output mode.
[1670] Pulse Output #29 Actual value of pulses applied to
[Hz] terminal 29 in digital output mode.
[1671] Relay Output [bin] View the setting of all relays.
[1672] Counter A View the present value of Counter
A.
[1673] Counter B View the present value of Counter
B.
[1675] Analog In X30/11 Actual value of the signal on input
X30/11 (General Purpose I/O Card.
Option)
[1676] Analog In X30/12 Actual value of the signal on input
X30/12 (General Purpose I/O Card.
Optional)
[1677] Analog Out X30/8 Actual value at output X30/8
[mA] (General Purpose I/O Card. Optional)
Use 6-60 Terminal X30/8 Output to
select the variable to be shown.
[1680] Fieldbus CTW 1 Control word (CTW) received from
the bus master.
[1682] Fieldbus REF 1 Main reference value sent with
control word via the serial
communications network, e.g., from
the BMS, PLC or other master
controller.
®
VLT HVAC Drive Programming Guide
0-20 Display Line 1.1 Small
Option:
[1684]
[1685]
[1686]
[1690]
[1691]
[1692]
[1693]
[1694]
[1695]
[1696]
[1830]
[1831]
[1832]
[1833]
[1834]
[1835]
[1836]
MG11CD22 - VLT ® is a registered Danfoss trademark
Function:
Comm. Option Extended serial communication
Status option status word.
FC Port CTW 1 Control word (CTW) received from
the bus master.
FC Port REF 1 Status word (STW) sent to the bus
master.
Alarm Word One or more alarms in a Hex code
(used for serial communications)
Alarm word 2 One or more alarms in a Hex code
(used for serial communications)
Warning Word One or more warnings in a Hex
code (used for serial communi-
cations)
Warning word 2 One or more warnings in a Hex
code (used for serial communi-
cations)
Ext. Status Word One or more status conditions in a
Hex code (used for serial communi-
cations)
Ext. Status Word 2 One or more status conditions in a
Hex code (used for serial communi-
cations)
Maintenance The bits reflect the status for the
Word programmed preventive
maintenance events in parameter
group 23-1*
Analog Input Shows the value of the signal
X42/1 applied to terminal X42/1 on the
Analog I/O card.
Analog Input Shows the value of the signal
X42/3 applied to terminal X42/3 on the
Analog I/O card.
Analog Input Shows the value of the signal
X42/5 applied to terminal X42/5 on the
Analog I/O card.
Analog Out X42/7 Shows the value of the signal
[V] applied to terminal X42/7 on the
Analog I/O card.
Analog Out X42/9 Shows the value of the signal
[V] applied to terminal X42/9 on the
Analog I/O card.
Analog Out Shows the value of the signal
X42/11 [V] applied to terminal X42/11 on the
Analog I/O card.
Analog Input
X48/2 [mA]
