3.8.3 6-2* Analog Input 2
Parameters for configuring the scaling and limits for
analog input 2 (terminal 54).
3 3
6-20 Terminal 54 Low Voltage
Range:
0.07 V [ 0.00 - par.
*
6-21 V]
6-21 Terminal 54 High Voltage
Range:
10.00 V [ par. 6-20 -
*
10.00 V]
6-22 Terminal 54 Low Current
Range:
4.00 [
mA par. 6-23
*
mA]
6-23 Terminal 54 High Current
Range:
20.00 mA [
*
20.00 mA]
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0.000 [-999999.999 -
*
999999.999 ]
6-25 Terminal 54 High Ref./Feedb. Value
Range:
100.000 [-999999.999 -
*
999999.999 ]
3-56
VLT
Function:
Enter the low voltage value. This analog
input scaling value should correspond
to the low reference/feedback value, set
in 6-24 Terminal 54 Low Ref./Feedb. Value.
Function:
Enter the high voltage value. This
analog input scaling value should
correspond to the high reference/
feedback value set in 6-25 Terminal 54
High Ref./Feedb. Value.
Function:
0.00 - Enter the low current value. This reference
signal should correspond to the low
reference/feedback value, set in
6-24 Terminal 54 Low Ref./Feedb. Value. The
value must be set at >2 mA in order to
activate the Live Zero Timeout Function in
6-01 Live Zero Timeout Function.
Function:
par. 6-22 - Enter the high current value
corresponding to the high reference/
feedback value set in 6-25 Terminal
54 High Ref./Feedb. Value.
Function:
Enter the analog input scaling
value that corresponds to the low
voltage/low current value set in
6-20 Terminal 54 Low Voltage and
6-22 Terminal 54 Low Current.
Function:
Enter the analog input scaling
value that corresponds to the
high voltage/high current value
set in 6-21 Terminal 54 High
MG11CD22 - VLT
®
HVAC Drive Programming Guide
6-25 Terminal 54 High Ref./Feedb. Value
Range:
6-26 Terminal 54 Filter Time Constant
Range:
0.001 s [0.001 -
*
10.000 s]
NOTE!
This parameter cannot be adjusted while the motor is
running.
6-27 Terminal 54 Live Zero
Option:
[0] Disabled
[1] Enabled
*
3.8.4 6-3* Analog Input 3 MCB 101
Parameter group for configuring the scale and limits for
analog input 3 (X30/11) placed on option module MCB
101.
6-30 Terminal X30/11 Low Voltage
Range:
0.07 V [
*
6-31 V]
6-31 Terminal X30/11 High Voltage
Range:
10.00 V [
*
10.00 V]
® is a registered Danfoss trademark
Function:
Voltage and 6-23 Terminal 54 High
Current.
Function:
Enter the time constant. This is a first-
order digital low pass filter time
constant for suppressing electrical noise
in terminal 54. A high time constant
value improves dampening but also
increases the time delay through the
filter.
Function:
This parameter makes it possible to disable the
Live Zero monitoring. For example, this to be
used if the analog outputs are used as part of a
de-central I/O system (e.g., when used not as part
of any adjustable frequency drive related control
functions, but for feeding a building management
system with data).
Function:
0.00 - par. Sets the analog input scaling value to
correspond to the low reference/
feedback value (set in 6-34 Term.
X30/11 Low Ref./Feedb. Value).
Function:
par. 6-30 - Sets the analog input scaling value to
correspond to the high reference/
feedback value (set in 6-35 Term.
X30/11 High Ref./Feedb. Value).
