Parameter Description
18-11 Fire Mode Log: Time
Range: Function:
0 s [0 - 2147483647 s] This parameter contains an array with
*
10 elements. The parameter shows at
which time the logged event occurred.
Time is measured in seconds since the
first start of the motor.
18-12 Fire Mode Log: Date and Time
Range: Function:
Size [ 0 - This parameter contains an array with 10
related 0 ] elements. The parameter shows at which
*
date and time the logged event occurred.
The function relies on the actual date and
time having been set in 0-70 Date and
Time. Note: There is no built-in battery
backup of the clock. An external backup
must be used, e.g., the one in the MCB 109
Analog I/O option card. See Clock Settings,
parameter group 0-7*.
3.17.3 18-3* Analog I/O
Parameters for reporting the digital and analog I/O ports.
18-30 Analog Input X42/1
Range: Function:
0.000 [-20.000 - Readout of the value of the signal applied
*
20.000 ] to terminal X42/1 on the Analog I/O Card.
The units of the value shown in the LCP
will correspond to the mode selected in
26-00 Terminal X42/1 Mode.
18-31 Analog Input X42/3
Range: Function:
0.000 [-20.000 - Readout of the value of the signal applied
*
20.000 ] to terminal X42/3 on the analog I/O card.
The units of the value shown in the LCP
will correspond to the mode selected in
26-01 Terminal X42/3 Mode.
18-32 Analog Input X42/5
Range: Function:
0.000 [-20.000 - Readout of the value of the signal applied
*
20.000 ] to terminal X42/5 on the analog I/O card.
The units of the value shown in the LCP
will correspond to the mode selected in
26-02 Terminal X42/5 Mode.
®
VLT HVAC Drive Programming Guide
18-33 Analog Out X42/7 [V]
Range:
0.000
18-34 Analog Out X42/9 [V]
Range:
0.000
18-35 Analog Out X42/11 [V]
Range:
0.000
3.17.4 18-5* Ref. & Feedb.
NOTE!
Sensorless Readout requires set up by MCT 10 with
sensorless specific plug-in.
18-50 Sensorless Readout [unit]
Range:
0.000 SensorlessUnit
MG11CD22 - VLT ® is a registered Danfoss trademark
Function:
[0.000 - Readout of the value of the signal
*
30.000 ] applied to terminal X42/7 on the Analog
I/O Card.
The value shown reflects the selection
in 26-40 Terminal X42/7 Output.
Function:
[0.000 - Readout of the value of the signal
*
30.000 ] applied to terminal X42/9 on the Analog
I/O Card.
The value shown reflects the selection
in 26-50 Terminal X42/9 Output.
Function:
[0.000 - Readout of the value of the signal
*
30.000 ] applied to terminal X42/11 on the
Analog I/O Card.
The value shown reflects the selection
in 26-60 Terminal X42/11 Output.
[-999999.999 - 999999.999
*
SensorlessUnit]
3 3
Function:
