How to Program
Step 4: Function setups choices appear. Choose Q3-1
2 2
General Settings. Press [OK].
Figure 2.20
Step 5: Use the up/down navigation keys to scroll down to,
e.g., Q3-11 Analog Outputs. Press [OK].
Figure 2.21
Function Setups parameters
The Function Setup parameters are grouped in the following way
Q3-10 Adv. Motor Settings
1-90 Motor Thermal Protection
1-93 Thermistor Source
1-29 Automatic Motor Adaptation
(AMA)
14-01 Switching Frequency
4-53 Warning Speed High
Table 2.3
2-10
®
VLT
28.4% 2.05A
Function Set-ups
Q3-1 General Settings
Q3-2 Open-loop Settings
Q3-3 Closed-loop Settings
Q3-4 Application Settings
26.0% 7.14A
General Settings
Q3 - 10 Adv. Motor Settings
Q3 - 11 Analog Output
Q3 - 12 Clock Settings
Q3 - 13 Display Settings
Q3-11 Analog Output
6-50 Terminal 42 Output
6-51 Terminal 42 Output Min
Scale
6-52 Terminal 42 Output Max
Scale
MG11CD22 - VLT
HVAC Drive Programming Guide
Step 6: Choose 6-50 Terminal 42 Output. Press [OK].
1(1)
Q3
Figure 2.22
Step 7: Use the up/down navigation keys to select
between the different choices. Press [OK].
1(1)
Q3-1
Figure 2.23
Q3-1 General Settings
Q3-12 Clock Settings
0-70 Date and Time
0-71 Date Format
0-72 Time Format
0-74 DST/Summertime
0-76 DST/Summertime Start
0-77 DST/Summertime End
® is a registered Danfoss trademark
26.3% 5.82A 1(1)
Analog Output 03.11
6 - 50 Terminal 42 Output
(100) Output frequency
43.4% 7.99A
Analog Output
Q3-11
6-50 Terminal 42 Output
Speed
[107]
Q3-13 Display Settings
0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-23 Display Line 2 Large
0-24 Display Line 3 Large
0-37 Display Text 1
0-38 Display Text 2
0-39 Display Text 3
1(1)
