Parameter Description
16-56 Feedback 3 [Unit]
Range:
0.000
3 3
ProcessCtrlUnit
16-58 PID Output [%]
Range:
0.0 %
*
3.16.4 16-6* Inputs & Outputs
16-60 Digital Input
Range: Function:
0 [0 - View the signal states from the active digital inputs.
1023 ] Example: Input 18 corresponds to bit no. 5, '0' = no
*
signal, '1' = connected signal. Bit 6 works in the
opposite way, on = '0', off = '1' (safe stop input).
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10-63
3-106
Function:
[-999999.999 - View value of Feedback 3,
999999.999 see parameter group 20-0*
*
ProcessCtrlUnit] Feedback.
The value is limited by
settings in 20-13 Minimum
Reference/Feedb. and
20-14 Maximum Reference/
Feedb.. Units as set in
20-12 Reference/Feedback
Unit.
[0.0 - 100.0 %]
Digital input term. 33
Digital input term. 32
Digital input term. 29
Digital input term. 27
Digital input term. 19
Digital input term. 18
Digital input term. 37
Digital input GP I/O term. X30/4
Digital input GP I/O term. X30/3
Digital input GP I/O term. X30/2
Reserved for future terminals
Table 3.23
MG11CD22 - VLT
®
VLT HVAC Drive Programming Guide
16-60 Digital Input
Range:
Function:
16-61 Terminal 53 Switch Setting
Option:
[0] Current
[1] Voltage
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
16-62 Analog Input 53
Range:
0.000
*
16-63 Terminal 54 Switch Setting
Option:
[0] Current
[1] Voltage
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
16-64 Analog Input 54
Range:
0.000
*
® is a registered Danfoss trademark
Function:
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
D I T - 3 3
D I T - 3 2
D I T - 2 9
D I T - 2 7
D I T - 1 9
D I T - 1 8
D I T - 3 7
D I X 3 0/4
D I X 3 0/3
D I X 3 0/2
D I X 4 6/ 1 3
D I X 4 6/ 1 1
D I X 4 6/9
D I X 4 6/ 7
D I X 4 6/ 5
D I X 4 6/3
D I X 4 6/ 1
Figure 3.43
Function:
View the setting of input terminal 53. Current =
0; Voltage = 1.
Function:
[-20.000 - 20.000 ] View the actual value at input 53.
Function:
View the setting of input terminal 54. Current =
0; Voltage = 1.
Function:
[-20.000 - 20.000 ] View the actual value at input 54.
