Parameter Description
Bit 0 CC Digital Output Terminal 27
Bit 1 CC Digital Output Terminal 29
Bit 2 GPIO Digital Output Terminal X 30/6
Bit 3 GPIO Digital Output Terminal X 30/7
Bit 4 CC Relay 1 output terminal
Bit 5 CC Relay 2 output terminal
Bit 6 Option B Relay 1 output terminal
Bit 7 Option B Relay 2 output terminal
Bit 8 Option B Relay 3 output terminal
Bit 9-15 Reserved for future terminals
Bit 16 Option C Relay 1 output terminal
Bit 17 Option C Relay 2 output terminal
Bit 18 Option C Relay 3 output terminal
Bit 19 Option C Relay 4 output terminal
Bit 20 Option C Relay 5 output terminal
Bit 21 Option C Relay 6 output terminal
Bit 22 Option C Relay 7 output terminal
Bit 23 Option C Relay 8 output terminal
Bit 24-31 Reserved for future terminals
Table 3.14
5-93 Pulse Out #27 Bus Control
Range:
0.00 % [0.00 - 100.00 %]
*
5-94 Pulse Out #27 Timeout Preset
Range:
0.00 % [0.00 - 100.00 %]
*
5-95 Pulse Out #29 Bus Control
Range:
0.00 % [0.00 - 100.00 %]
*
5-96 Pulse Out #29 Timeout Preset
Range:
0.00 % [0.00 - 100.00 %]
*
5-97 Pulse Out #X30/6 Bus Control
Range:
0.00 % [0.00 - 100.00 %]
*
5-98 Pulse Out #X30/6 Timeout Preset
Range:
0.00 % [0.00 - 100.00 %]
*
®
VLT HVAC Drive Programming Guide
Function:
Function:
Function:
Function:
Function:
Function:
