Parameter Description
13-02 Stop Event
Option: Function:
trip-locked) and the reset button is
pressed.
[42] Auto Reset Trip This event is TRUE if the Adjustable
frequency drive is tripped (but not
trip-locked) and an automatic reset is
issued.
[43] OK Key This event is TRUE if the OK key on
the LCP is pressed.
[44] Reset Key This event is TRUE if the reset key on
the LCP is pressed.
[45] Left Key This event is TRUE if the left key on
the LCP is pressed.
[46] Right Key This event is TRUE if the right key on
the LCP is pressed.
[47] Up Key This event is TRUE if the up key on
the LCP is pressed.
[48] Down Key This event is TRUE if the down key on
the LCP is pressed.
[50] Comparator 4 Use the result of comparator 4 in the
logic rule.
[51] Comparator 5 Use the result of comparator 5 in the
logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the
logic rule.
[61] Logic rule 5 Use the result of logic rule 5 in the
logic rule.
[70] SL Timeout 3 Use the result of timer 3 in the logic
rule.
[71] SL Timeout 4 Use the result of timer 4 in the logic
rule.
[72] SL Timeout 5 Use the result of timer 5 in the logic
rule.
[73] SL Timeout 6 Use the result of timer 6 in the logic
rule.
[74] SL Timeout 7 Use the result of timer 7 in the logic
rule.
[76] Digital Input x30 2
[77] Digital Input x30 3
[78] Digital Input x30 4
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive Mode
[91] ECB Bypass Mode
®
VLT HVAC Drive Programming Guide
13-02 Stop Event
Option:
[92]
[100] Fire Mode
13-03 Reset SLC
Option:
[0]
[1]
3.13.3 13-1* Comparators
Comparators are used for comparing continuous variables
(i.e., output frequency, output current, analog input, etc.)
to fixed preset values.
Figure 3.32
In addition, there are digital values that will be compared
to fixed time values. See explanation in 13-10 Comparator
Operand. Comparators are evaluated once in each scan
interval. Use the result (TRUE or FALSE) directly. All
parameters in this parameter group are array parameters
with index 0 to 5. Select index 0 to program Comparator 0,
select index 1 to program Comparator 1, etc.
13-10 Comparator Operand
Array [4]
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
MG11CD22 - VLT ® is a registered Danfoss trademark
Function:
ECB Test Mode
Function:
Do not reset Retains programmed settings in all group
*
SLC 13 parameters (13-**).
Reset SLC Resets all group 13 parameters (13-**) to
default settings.
Par. 13-11
Comparator Operator
Par. 13-10
Comparator Operand
=
TRUE longer than.
Par. 13-12
. . .
Comparator Value
. . .
Function:
Select the variable to be monitored
by the comparator.
DISABLED
*
Reference
Feedback
Motor speed
Motor current
Motor torque
Motor power
Motor voltage
DC-link voltage
Motor thermal
