How to Program
2.1.12 Value, Step-by-Step
Certain parameters can be changed step by step or
infinitely varying. This applies to 1-20 Motor Power [kW],
1-22 Motor Voltage and 1-23 Motor Frequency.
The parameters are changed both as a group of numeric
data values and as numeric data values infinitely varying.
2.1.13 Readout and Programming of
Indexed Parameters
Parameters are indexed when placed in a rolling stack.
15-30 Alarm Log: Error Code to 15-33 Alarm Log: Date and
Time contain a fault log which can be read out. Choose a
parameter, press [OK], and use the up/down navigation
keys to scroll through the value log.
Use 3-10 Preset Reference as another example:
Choose the parameter, press [OK], and use the up/down
navigation keys to scroll through the indexed values. To
change the parameter value, select the indexed value and
press [OK]. Change the value by using the up/down keys.
Press [OK] to accept the new setting. Press [Cancel] to
abort. Press [Back] to leave the parameter.
2.1.14 Initialization to Default Settings
Initialize the adjustable frequency drive to default settings
in two ways.
Recommended initialization (via 14-22 Operation Mode)
1. Select 14-22 Operation Mode
2. Press [OK]
3. Select "initialization"
4. Press [OK]
5. Cut off the line power supply and wait until the
display turns off.
6. Reconnect the line power supply - the adjustable
frequency drive is now reset.
7. Change 14-22 Operation Mode back to Normal
Operation.
NOTE!
Resets parameters selected in Personal Menu with default
factory setting.
®
VLT HVAC Drive Programming Guide
Manual initialization
1.
2a.
2b.
3.
4.
This procedure initializes all except: 15-00 Operating Hours;
15-03 Power-ups; 15-04 Over Temps; 15-05 Over Volts.
Table 2.8
NOTE!
When you carry out manual initialization, you also reset
serial communication, 14-50 RFI 1 and fault log settings.
Removes parameters selected in 25-00 Cascade Controller.
NOTE!
After initialization and power cycling, the display will not
show any information for a couple of minutes.
MG11CD22 - VLT ® is a registered Danfoss trademark
14-22 Operation Mode initializes all except
14-50 RFI 1
8-30 Protocol
8-31 Address
8-32 Baud Rate
8-35 Minimum Response Delay
8-36 Maximum Response Delay
8-37 Maximum Inter-Char Delay
15-00 Operating Hours to 15-05 Over Volts
15-20 Historic Log: Event to 15-22 Historic Log: Time
15-30 Alarm Log: Error Code to 15-32 Alarm Log:
Time
Disconnect from the line power and wait until the
display turns off.
Press [Status] - [Main Menu] - [OK] at the same time
while powering up for LCP 102, Graphical Display
Press [Menu] while powering up for LCP 101, Numerical
Display
Release the keys after 5 seconds
The adjustable frequency drive is now programmed
according to default settings.
