Danfoss VLT FC 100 Series Programming Manual page 109

Parameter Description
13-10 Comparator Operand
Array [4]
Option:
3 3
[10] VLT temp.
[11] Heat sink temp.
[12] Analog input AI53
[13] Analog input AI54
[14] Analog input AIFB10
[15] Analog input AIS24V
[17] Analog input AICCT
[18] Pulse input FI29
[19] Pulse input FI33
[20] Alarm number
[21] Warning number
[22] Analog input x30 11
[23] Analog input x30 12
[30] Counter A
[31] Counter B
[40] Analog input x42/1
[41] Analog input x42/3
[42] Analog input x42/5
[50] FALSE
[51] TRUE
[52] Control ready
[53] Drive ready
[54] Running
[55] Reversing
[56] In range
[60] On reference
[61] Below reference, low
[62] Above ref, high
[65] Torque limit
[66] Current limit
[67] Out of current range
[68] Below I low
[69] Above I high
[70] Out of speed range
[71] Below speed low
[72] Above speed high
[75] Out of feedb. range
[76] Below feedb. low
[77] Above feedb. high
[80] Thermal warning
[82] Line pwr out of range
[85] Warning
[86] Alarm (trip)
[87] Alarm (trip lock)
[90] Bus OK
[91] Torque limit & stop
[92] Brake fault (IGBT)
[93] Mech. brake control
3-82
®
VLT HVAC Drive Programming Guide
Function:
MG11CD22 - VLT ® is a registered Danfoss trademark
13-10 Comparator Operand
Array [4]
Option: Function:
[94] Safe stop active
[100] Comparator 0
[101] Comparator 1
[102] Comparator 2
[103] Comparator 3
[104] Comparator 4
[105] Comparator 5
[110] Logic rule 0
[111] Logic rule 1
[112] Logic rule 2
[113] Logic rule 3
[114] Logic rule 4
[115] Logic rule 5
[120] SL Timeout 0
[121] SL Timeout 1
[122] SL Timeout 2
[123] SL Timeout 3
[124] SL Timeout 4
[125] SL Timeout 5
[126] SL Timeout 6
[127] SL Timeout 7
[130] Digital input DI18
[131] Digital input DI19
[132] Digital input DI27
[133] Digital input DI29
[134] Digital input DI32
[135] Digital input DI33
[150] SL digital output A
[151] SL digital output B
[152] SL digital output C
[153] SL digital output D
[154] SL digital output E
[155] SL digital output F
[160] Relay 1
[161] Relay 2
[180] Local ref. active
[181] Remote ref. active
[182] Start command
[183] Drive stopped
[185] Drive in hand mode
[186] Drive in auto mode
[187] Start command given
[190] Digital input x30 2
[191] Digital input x30 3
[192] Digital input x30 4
