3.7.3

Active state

Select the active state of the output. The available options are:
•
•
Note:
3.7.4

Configuring Outputs

To configure the outputs for an Aperio Door Controller panel
1.
2.
3.
4.
Continue with your configuration settings. After you have completed all of your
configuration settings, connect to your TX3 system and send the job (see section
3.13, Sending Your Configuration, on page 98).
3.8

Correlations

Correlations let you establish specific relationships between events at a panel
(for example, an input becomes active or an access point reports a forced entry)
and the action to perform when that event happens (for example, energize an
output or go into high security mode). You can also tie a correlation to a schedule,
so that actions are only performed during certain days and times of the week. A
maximum of 32 correlations are allowed.
To access the correlations for a panel in the TX3 Configurator, expand the panel
in the job tree, and then select the Correlations entry for that panel. The
right pane shows the Correlation Configuration window for your panel (see
Figure 41). The Correlation Configuration window shows the panel's
TX3 Aperio Door Controller System Installation and Operation Manual
v. 1.6
LT-1160 Copyright 2019
Energized
De-energized
If you are using Outputs 7 and 8 to power hubs, leave them as
De-energized.
Expand the entry for your panel in the job tree, and then select the
Inputs/Outputs entry for the panel.
Select the Outputs option in the right pane.
Select an output and then set the following options for that input:
• Label
• Active state
Information on each of these options can be found in sections 3.7.1 and
3.7.3.
Repeat step 3 for all of the outputs that you have installed on your panel.
Configuration
85
