3.6.5

Alarm delay

Alarm delay specifies the amount of time the input must be active before an
alarm is raised.
3.6.6

Configuring Inputs

To configure the inputs for an Aperio Door Controller panel
1.
2.
3.
4.
Continue with your configuration settings. After you have completed all of your
configuration settings, connect to your TX3 system and send the job (see section
3.13, Sending Your Configuration, on page 98).
3.7

Aperio Door Controller Outputs

Each Aperio Door Controller has eight general purpose outputs. Outputs can be
turned off or on in a correlation when an input becomes active or when an access
point is in a certain state (see section 3.8). For example, a correlation can be
written to turn on one of the general purpose outputs when an input becomes
active or when an access point reports a forced entry alarm.
TX3 Aperio Door Controller System Installation and Operation Manual
v. 1.6
LT-1160 Copyright 2019
Expand the entry for your panel in the job tree, and then select the
Inputs/Outputs entry for the panel.
Select the Inputs option in the right pane.
Select an input and then set the following options for that input:
• Label
• Active state
• Circuit supervision
• Alarm delay
Information on each of these options can be found in sections 3.6.1 to
3.6.5.
Repeat step 3 for all of the inputs that you have installed on your panel.
