3.1 Configuring Aperio Door Controller panels with
the TX3 Configurator
TX3 Configurator software is used to configure your Aperio Door Controller
panel (as well as any other TX3 panels in your TX3 system). Before you can
configure an Aperio Door Controller panel, you must create a job that has an
Aperio Door Controller added to it.
Note:
3.1.1

Creating a New Job

This section describes two methods for creating a new job with the TX3
Configurator software. The first method creates a new job using a template. This
method is recommended for an installation with a single panel that is not
connected to any other TX3 devices. The second method creates a new job by
reading all of the panels on the network. This method is recommended for an
installation where the Aperio Door Controller panel is connected to other TX3
panels using either an RS-485 network, a TCP/IP network, or a TCP/IP network
with RS-485 subnetworks (see section 1.5, Network Setup, on page 12 for more
information on TX3 networks).
3.1.1.1 Creating a New Job Using a Template
Use a template to create a new job that with a single a stand-alone Aperio Door
Controller panel.
To create a new job using a template
1.
2.
3.
4.
5.
6.
TX3 Aperio Door Controller System Installation and Operation Manual
66
LT-1160 Copyright 2019
To perform the tasks described in this chapter, you must have a
computer with the latest version of the TX3 Configurator software.
Details on how to install the software and drivers can be found in
LT-995, the TX3 Series Configuration and Administration Manual.
Start the TX3 Configurator.
Enter your username and password, and then click Login.
By default, the username is administrator and there is no password.
Click File > New Job.
Enter a name for the job in the Job name text box.
(Optional) Enter a description for the job in the Description text box.
Select Create from a template.
