To specify what action to take, select an action from the Action list. The
available choices from the Action menu are the following:
•
•
•
•
To specify where the action will happen, you have to choose the panel(s) and
either the output(s) or the access point(s) on the panel(s).
To choose a panel, select one of the following options from the On panel list:
•
•
•
Note:
TX3 Aperio Door Controller System Installation and Operation Manual
v. 1.6
LT-1160 Copyright 2019
Turn ON output: turn on one or more outputs.
Turn OFF output: turn off one or more outputs.
Turn ON high security: turn on high security mode on one or more
access points. When you turn on high security mode at an access point,
only cards with the high security privilege can open the door.
Turn OFF high security: turn off high security mode on one or more
access points.
Panel: choose a panel from the list of panels in your job.
All: apply the correlation to all of the Aperio Door Controller panels, Card
Access panels, Telephone Access panels, and Touch Screen panels in
your job.
Custom: apply the correlation to a custom target. This option is only
available if you have a TCP/IP network connection to your TX3 system. If
you select the Custom option, click the Custom button to open the
Custom Correlation Target window, and then select the targets for your
correlation. You can choose from the following targets:
• All nodes on the RS-485 network of the Master Node: select a
Master Node from the list. The correlation affects all of the nodes
on the Master Node's RS-485 subnetwork.
• All Master Nodes only: the correlation affects only the Master
Nodes on your TCP/IP network.
• All panels with RS485 address: select an RS-485 address from the
list. The correlation affect all panels with this RS-485 address on all
of the RS-485 subnetworks.
Correlation signals cannot be transmitted by Touch Screen Master
Nodes. If you plan on using the All or Custom correlation options,
you should not have any Touch Screen Master Nodes on your
network.
• Nano - Apply the correlation to a TX3 Nano. This option is only
available for TCP/IP network connections. When you select this
option, you can click on the Nano button and enter the IP address of
a TX3 Nano. Click Find to find any TX3 Nanos on the network.
