Auto-Unlock; Pin Required; Setting An Access Point Schedule - Mircom TX3 Series Installation And Operation Manual

You must define the schedule for your mode before you can configure the access
point for that schedule. By default, two schedules are programmed into the TX3
Configurator: Always and Never. If you want to set a custom schedule for an
access point mode, see section 3.11, Schedules, on page 96.
3.3.1

Auto-unlock

During an auto-unlock schedule, the wireless device automatically unlocks and
stays unlocked until the end of the schedule.
Note:
3.3.2

PIN required

During the PIN required schedule, users will have to swipe a valid card at the
device and then enter their PIN code in order to gain access. The PIN code is 1 to
4 digits long and must be set in the options for the card (see section 3.10, Cards,
for information on configuring cards). 0 is not a valid PIN code.
Note:
3.3.3

Setting an Access Point Schedule

Access points can operate in Auto-unlock and PIN required modes
according to a schedule for each mode. In order to set a schedule for a mode, the
schedule must already be defined (see section 3.11, Schedules, on page 96).
To set the schedule for an access point mode
1.
2.
3.
4.
5.
TX3 Aperio Door Controller System Installation and Operation Manual
v. 1.6
LT-1160 Copyright 2019
In order for the Aperio Door Controller to unlock a wireless device
remotely, the Remote Open option must be set for the wireless
device. See section 2.7.4, Enabling Remote Open, on page 49 for
information on how to do this.
This feature requires a wireless device with a keypad.
Find the access point in the job tree.
If you do not see the access point in your job tree, expand the Aperio Door
Controller panel entry, and then expand the panel's Access Point
entry.
Click on the access point.
Select the Timers tab.
To set an auto-unlock schedule, select a schedule from the
Auto-unlock schedule list.
To set a PIN required schedule, select a schedule from the PIN
required schedule list.
Configuration
75
