Mircom TX3 Series Installation And Operation Manual page 36

G.
H.
2.6.2.3 Powering the Aperio hubs
The power requirements for the Aperio hubs are as follows.
To power the Aperio hub, connect the positive voltage output of your power
supply to the 8-24VDC terminal on the J100 connector and the ground of your
power supply to the GND port of the J100 connector (see Figure 20).
See section 2.5.3 on page 29 for information about powering the Aperio hubs
from outputs 7 and 8.
Note:
2.6.2.4 Installing the Aperio hub
This section describes how to install the Aperio hub on the following standard
assemblies:
•
•
•
•
TX3 Aperio Door Controller System Installation and Operation Manual
36
LT-1160 Copyright 2019
One of the Aperio hubs must have DIP switches 6 (DOWN) and 7 (UP) set
to ON (see Figures 21 and 22).
Jumpers JW1 and JW2 on the MD-1113 are open. This is the factory
default setting.
• 8-24 VDC
• 250 mA
If you use one or both of Outputs 7 and 8 to power your Aperio hubs,
do not use these outputs in your correlations (see section 3.8,
Correlations, on page 85).
Switch box assembly
Square box assembly
Octagon box assembly
Handy box assembly
Installation and Setup
v. 1.6
