To add and configure an access point
1.
2.
Notes:
3.
TX3 Aperio Door Controller System Installation and Operation Manual
v. 1.6
LT-1160 Copyright 2019
Right-click on the Aperio Door Controller panel, and then select Add
Access Point.
A new access point is added and the Access Point Configuration window
opens. The Configurator automatically assigns values for the Hub
Address and the Lock Address. In the following steps you will change
these values to match the Hub and Lock Addresses programmed into your
wireless device.
Figure 39. The Access Point Configuration window
Select the Hub Address of the device from the list.
The Hub Address is the RS-485 address setting for the Aperio hub that the
wireless device is paired to. You can select a value from 1 to 15.
• If the Hub Address and Lock Address combination you want to
select have already been assigned to another device, you will get
an error. If you know that your values are correct, find the other
access point and then change its Hub and Lock Address settings.
• If you followed the instructions in section 2.7.2, Pairing a
Wireless Device to an Aperio Hub, there should be a label on
the device with the Hub Address and Lock Address. If you did
not label your device, you must use the Aperio Programming
Application to find these values. See section 2.7.2, Pairing a
Wireless Device to an Aperio Hub, on page 38 for more
information on pairing and finding these addresses.
Select the Lock Address of the access point from the list.
You can select from a value from 0 to 7 for your Lock Address.
Configuration
73
