TX3 Aperio Door Controller System Installation and Operation Manual
v. 1.6
LT-1160 Copyright 2019
• Inactive
Inactive cards are not granted access. Active cards are granted access
provided all the other conditions like access level and privilege are met.
Usage counter. The usage counter is used for temporary cards. Select the
checkbox and specify a value from 1 to 255. Using 255 means there is no
restriction on usage. If any other value is used, it means the card is only
usable for that number of times.
For the usage counter to function, you must select the deduct usage
count option for the access point (see section 3.5.3, Deduct usage
count).
Select the Advanced tab, and then set the following options:
High security privilege. When this option, the card has the following
privileges:
• Opens doors in high security mode.
• Enables and disables high security mode by presenting the card four
times in succession.
Extended unlock time. When this option is enabled the door opens for the
extended unlock time (see section 3.4.2, Extended Unlock Time). This
option is normally given to seniors and persons with mobility issues.
Ignore anti-passback. When this option is enabled the card holder is not
restricted by the timed anti-passback mode.
Handicap. When this option is enabled the output designated as
accessible is activated along with the main door.
This option does not apply to Aperio Door Controller because all of
their outputs are general purpose outputs. However, if your job
contains any TX3-CX Two Card Access Controllers that have
outputs designated as accessible, this option will apply for those
outputs.
Lock/Unlock privilege. When this option is enabled the user has the
privilege of unlocking the door by presenting the card to the reader twice
in succession.
First person in. This option works only for access points with both an
Auto-unlock schedule and the First person in option set. If this option is
enabled, the user can set the access point to unlock mode by presenting the
card during the Auto-unlock schedule. The access point remains
unlocked until the end of the Auto-unlock schedule.
