TX3 Aperio Door Controller System Installation and Operation Manual
v. 1.6
LT-1160 Copyright 2019
Provide information for the following:
Panel label. Provide a name for the Panel.
Panel model. The application automatically retrieves the selected panel
model information. This field is read only.
Address. The drop down list displays the remaining available panel
addresses. From this list select the panel address. This field is disabled if a
connection is active. Ensure that this address matches the panel address.
Master Node. If you are connected to your TX3 system through TCP/IP,
this option lets you either configure the panel as a Master Node (select
This is a master from the list) or specify the Master Node for your panel
(select the Master Node from the list).
Test Connection. This option tests the connection between your
computer and a Master Node. You can only test the connection to a Master
Node panel. You must be connected to the TX3 system in order to use
Test Connection.
IP address. The IP address of your panel if it is a Master Node on a TCP/
IP network. This field only appears if you are connected to your TX3
system through TCP/IP.
You cannot change a Master Node's IP address by editing the IP
address field. To change a Master Node's IP address, use the IP
Change Tool. See LT-995, the TX3 Configurator Configuration
and Administration Manual, for details on how to use the IP Change
Tool.
Provide information for each of the following:
Card format. Select the card reader format for panel. See section 1.3.1 on
page 11 for the list of supported formats. Select only the formats that are
being used. In addition, do not select more than one format with the same
bit length. For example, select either 36-bit HID Simplex or 36-bit
Keyscan, but do not select both.
Card discovery mode. Enable this option, then send the Job to the panel
to put the panel into card discovery mode. While the panel is in card
discovery mode and you present a card to the reader, the panel will display
the card's raw data in the Online Events pane. To disable the feature,
uncheck Card discovery mode, then send the job to the panel again.
Custom Formats. See LT-995 on the USB flash or
http://www.mircom.com for instructions on creating custom card
formats.
Report real time events to PC. Enable or disable real time event sending
to the PC. If enabled, only the real time logs are sent to the PC.
