Description of the line
Moreover, by touching the other input boxes you can change the operation of the top belt
(long-moulding belt):
T
OP BELT
B
OTTOM BELT
R -1
OLL
R -2
OLL
In the optional menu item 'Flour duster', you can enter the values for operating the flour
duster by touching the input fields:
P
RESET
S
TART FLOUR
DUSTER
D
UST TIME
D
USTING
QUANTITY
In the optional menu item 'Timing roller', use the drop-down menu
to select between the following four alignment and pressure roller settings:
O
FF
S
YNCHRONOUS
S
YNCHRONOUS
- O
PPOSITE
O
PPOSITE
/S
TOP
Moreover, you can change operation of the timing roller by touching the other input fields
S
TART CHANGE
S
TART CHANGE
R
UNTIME
Emil Kemper GmbH
Input of the top belt speed from 15 to 75 Hertz.
Input of the bottom belt (conveyor belt) speed from 15 to 75 Hertz.
Selection of 'On' or 'Off'. Operation of the first roll-out roller can be
switched on or off.
Selection of 'On' or 'Off'. Operation of the second roll-out roller can be
switched on or off.
Selection of 'On' or 'Off'. Operation of the flour duster can be switched on
or off.
Input of the start time of the flour duster between 1 and 17 pulses. The
flour duster starts at this time.
Input of the dust time of the flour duster as from the start time between 2
and 10 pulses.
Input of the speed of the round brushes in the flour duster in Hertz.
The timing roller is out of operation. The timing roller is manually set via
the adjusting wheel of the transport route (see section "7.4.12 Setting the
alignment and pressure roller (timing roller)").
The timing roller rotates in running direction to flatten the pieces of dough.
The timing roller rotates in the opposite direction to the running direction
to align the pieces of dough . The timing roller subsequently changes to
synchronous.
The timing roller rotates in the opposite direction to the running direction
and subsequently stops.
and R :
UNTIME
Input of the start time between 1 and 17 pulses after which the timing roller
returns to synchronous.
Input of the synchronous runtime from a start time of between 3 and 12
pulses.
